Victron Energy SmartSolar MPPT 100/20 20A Solar Charge Controller up to 48V | SCC110020160R

The Victron Energy SmartSolar MPPT 100/20 | SCC110020160R is a high-efficiency solar charge controller designed to optimize photovoltaic energy harvesting and deliver intelligent battery charging for 12V, 24V, and 48V battery systems. Featuring advanced Maximum Power Point Tracking (MPPT) technology, a rated charging current of 20A, and support for photovoltaic input voltages up to 100V, this controller provides efficient solar charging for a wide variety of off-grid and battery-based renewable energy applications.

With up to 98% peak conversion efficiency, the SmartSolar MPPT 100/20 continuously adjusts the operating point of connected solar panels to harvest available solar energy efficiently, including during changing weather and sunlight conditions. Its adaptive multi-stage charging algorithm supports effective battery charging while helping maintain appropriate charging conditions for compatible battery technologies.

The controller supports nominal photovoltaic charging capacities of 290W at 12V, 580W at 24V, and 1,160W at 48V. Automatic battery voltage detection simplifies system configuration, while the integrated load output provides additional control and battery discharge protection for compatible DC loads.

As part of the Victron SmartSolar family, the SCC110020160R includes integrated Bluetooth connectivity for configuration and monitoring through the VictronConnect app. A VE.Direct communication port also supports connection to compatible Victron monitoring and control equipment.

Key Technology

• Advanced MPPT Solar Charging: Continuously tracks the maximum power point of connected photovoltaic panels to optimize available solar energy production.
• 20A Rated Charge Current: Provides controlled charging for compatible battery systems.
• 12V, 24V, and 48V Battery Support: Automatically detects supported nominal battery system voltages.
• 100V Maximum PV Input: Supports appropriately configured photovoltaic arrays within the controller's input voltage limit.
• Up to 98% Peak Efficiency: Delivers efficient conversion of photovoltaic energy into battery charging power.
• Adaptive Multi-Stage Charging: Adjusts battery charging behavior according to configured charging parameters and operating conditions.
• Integrated Bluetooth: Supports wireless monitoring and configuration through the VictronConnect application.
• VE.Direct Communication: Enables integration with compatible Victron monitoring and system management accessories.
• BatteryLife Function: Helps protect batteries from excessive discharge by intelligently managing connected DC loads.
• Programmable Load Output: Supports controlled operation of compatible DC loads.
• Automatic Load Disconnect: Disconnects connected loads when configured low-voltage conditions are reached.
• Overtemperature Protection: Provides protection against excessive operating temperatures.
• Output Short-Circuit Protection: Helps protect the controller against specified electrical faults.
• Low-Light Energy Harvesting: MPPT technology supports efficient charging during variable sunlight conditions.
• Victron Energy Ecosystem Integration: Works with compatible Victron monitoring and battery system components.

Best Uses

• Off-Grid Solar Systems: Suitable for charging compatible battery banks in standalone photovoltaic installations.
• Residential Battery-Based Solar Systems: Provides intelligent solar charging for smaller and supplemental battery storage applications.
• 48V Solar Battery Systems: Supports compatible 48V battery banks with appropriately sized photovoltaic arrays.
• RV and Camper Solar Systems: Provides efficient solar charging for mobile battery-powered applications.
• Marine Solar Installations: Suitable for appropriately protected battery charging systems on boats and other marine applications.
• Cabins and Remote Properties: Supports solar battery charging where utility electricity is unavailable or limited.
• Telecommunications and Remote Equipment: Suitable for compatible battery-supported remote electrical equipment.
• DC Lighting and Small Loads: Supports compatible loads through the controller's load output.
• Solar System Monitoring: Enables convenient charging configuration and performance monitoring through VictronConnect.

Product Specifications

Efficient and Intelligent Solar Battery Charging with Victron SmartSolar Technology

The Victron Energy SmartSolar MPPT 100/20 SCC110020160R combines advanced MPPT solar energy harvesting, multi-voltage battery support, adaptive charging technology, integrated Bluetooth, VE.Direct communication, and intelligent load management. Designed for reliable solar charging across compatible battery-based energy systems, it provides a flexible solution for off-grid, mobile, and residential photovoltaic applications.
