Victron Energy Phoenix 24V 500VA 120V Pure Sine Wave Inverter with VE.Direct & NEMA 5-15R – PIN245010500

The Victron Energy Phoenix 24V 500VA 120V Pure Sine Wave Inverter | PIN245010500 is a compact, high-efficiency DC-to-AC power inverter designed to deliver reliable household-quality electricity from a nominal 24V battery system. Featuring advanced pure sine wave technology, a standard NEMA 5-15R AC receptacle, VE.Direct communication, and intelligent ECO mode functionality, the Phoenix 24/500 provides dependable AC power for off-grid solar systems, recreational vehicles, marine applications, and remote electrical installations.

With a 500VA continuous apparent power rating, 400W continuous real power output at 25°C, and 900W peak power capability, this inverter is designed to operate compatible electronic devices, lighting, small appliances, and other AC loads. Its full-bridge and toroidal transformer architecture provides reliable power conversion and high startup capability for appropriately sized equipment.

The PIN245010500 configuration features a 120V NEMA 5-15R receptacle for connection of compatible North American electrical equipment. Its VE.Direct communication port enables configuration and monitoring through compatible Victron accessories and the VictronConnect application.

Additional features include up to 90% maximum efficiency, configurable low-battery protection, remote on/off control, ECO energy-saving mode, and integrated electrical protection. The Phoenix 24/500 is designed for standalone inverter applications requiring efficient conversion of stored battery energy into usable AC electricity.

Important: This model includes a standard NEMA 5-15R receptacle, not a GFCI receptacle. It is a standalone inverter and does not include an integrated battery charger, solar charge controller, or automatic transfer switch.

Key Technology

• 500VA Pure Sine Wave Inverter: Converts nominal 24V DC battery electricity into stable 120V AC power.
• 400W Continuous Output: Supplies sustained real power for compatible electrical equipment at the specified operating temperature.
• 900W Peak Power: Provides additional short-duration output for suitable equipment with elevated startup requirements.
• Full-Bridge and Toroidal Transformer Design: Combines proven inverter architecture with reliable power conversion.
• 90% Maximum Efficiency: Supports efficient use of stored battery energy.
• 24V Battery Compatibility: Designed for appropriately configured nominal 24V battery banks.
• 120V Pure Sine Wave Output: Provides high-quality AC electricity for compatible North American equipment.
• NEMA 5-15R Receptacle: Features a standard North American AC outlet.
• VE.Direct Communication: Supports configuration and monitoring through compatible Victron interfaces.
• VictronConnect Compatibility: Enables access to supported inverter settings and operating information.
• Optional Bluetooth Monitoring: Supports wireless communication using a separately available VE.Direct Bluetooth Smart dongle.
• Intelligent ECO Mode: Reduces power consumption during suitable low-load conditions.
• Dynamic Low-Voltage Cutoff: Supports configurable battery protection based on electrical load.
• Adjustable Battery Voltage Thresholds: Allows supported low-voltage shutdown, restart, and alarm settings to be configured.
• Remote On/Off Capability: Supports control through a compatible external switch.
• Overload and Short-Circuit Protection: Helps protect the inverter during specified electrical faults.
• Overtemperature Protection: Protects against excessive internal operating temperatures.
• Battery Voltage Protection: Includes protection against high and low DC input voltage.
• DC Ripple Protection: Helps protect against excessive DC input voltage ripple.
• Compact Standalone Design: Suitable for smaller battery-powered AC installations.

Best Uses

• Off-Grid Solar Power Systems: Converts stored battery energy into usable AC electricity for small standalone photovoltaic installations.
• Recreational Vehicles and Campervans: Provides AC electricity for compatible electronics and small appliances.
• Marine Electrical Systems: Suitable for properly installed battery-based AC power applications on boats.
• Remote Cabins and Sheds: Supports smaller AC electrical loads where utility power is unavailable.
• Portable Battery Power Systems: Provides AC electricity from compatible nominal 24V battery banks.
• Small Electronics and Lighting: Powers suitable AC equipment within the inverter's continuous output rating.
• Remote Monitoring Equipment: Supplies pure sine wave AC power for compatible electronic systems.
• Mobile Workstations: Provides battery-powered electricity for appropriately sized devices and tools.
• Residential Backup Applications: Supports selected small electrical loads in properly designed battery backup installations.

Product Specifications

Compact and Reliable Pure Sine Wave Power with Victron Phoenix Technology

The Victron Energy Phoenix 24V 500VA 120V Pure Sine Wave Inverter with VE.Direct & NEMA 5-15R PIN245010500 combines dependable pure sine wave power conversion, high startup capability, intelligent ECO mode, configurable battery protection, and VE.Direct communication. Designed for compatible 24V battery-based systems, it provides a practical AC power solution for off-grid, mobile, marine, and remote electrical applications.
