Victron GXEasySolar-II 48/3000/35-32 MPPT 250/70 prewired Inverter

Victron GXEasySolar-II 48/3000/35-32 MPPT 250/70 prewired Inverter

Regular price $1,400
Sale price $1,400 Regular price
SOLD OUT
Leave a Review

MPN No: 48/3000/35-32 MPPT 250/70 GX

Victron GXEasySolar-II 48/3000/35-32 MPPT 250/70 prewired Inverter

Victron GXEasySolar-II 48/3000/35-32 MPPT 250/70 prewired Inverter

Regular price $1,400
Sale price $1,400 Regular price

View full details
.PDF
Datasheet
Description
Questions
Reviews
Default manufacturer logo
Manufacturer
Victron Energy
Weight
57.3 lb
Dimension
19.6 x 10.6 x 9.3 inches

Victron GXEasySolar-II 48/3000/35-32 MPPT 250/70 Prewired Inverter

The Victron GXEasySolar-II represents an all-in-one solar power solution, integrating a MultiPlus-II inverter/charger, a SmartSolar MPPT charge controller, and a GX device within a single, prewired unit. This integration simplifies installation and enhances efficiency, offering an unmatched combination of convenience and performance.

  • Seamless integration of inverter/charger and MPPT charge controller for streamlined installation and operation.
  • SmartSolar MPPT technology ensures maximum efficiency from solar panels.
  • Integrated GX device for comprehensive system monitoring and control, including remote access capabilities.
  • Wi-Fi and Ethernet connectivity for easy setup and adjustments via smartphone or online portal.
  • Automatic transfer switch and PowerControl/PowerAssist features for efficient energy management.

Technology and Overview

Incorporating Victron's advanced technology, the GXEasySolar-II offers robust power conversion and smart energy management in one compact package.

Installation and Compatibility Overview

Designed for straightforward installation, this system is compatible with a variety of applications, ensuring flexibility across different energy setups.

Benefits and Applications Overview

From cost savings to environmental impact reduction, the GXEasySolar-II is ideal for anyone looking to enhance their energy system's efficiency and reliability.

Specifications

Specification Values
EasySolar-II 48/3000/35-32
MPPT 250/70 GX
PowerControl & PowerAssist Yes
Transfer switch 32 A
Maximum AC input current 32 A
Auxiliary output 32 A
Input voltage range 38 – 66 V
Output Output voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0,1 % (1)
Cont. output power at 25 °C (3) 3000 VA / 2400 W
Cont. output power at 40 °C / 55 °C 2200 W / 1700 W
Maximum apparent feed-in power 2470W / 3000 VA
Peak power 5500 W
Maximum efficiency 95%
Zero load power 11 W
Zero load power in AES mode 7 W
Zero load power in Search mode 2 W
AC Input Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz
Charge voltage 'absorption' 57,6 V
Charge voltage 'float' 55,2 V
Storage mode 52,8 V
Maximum battery charge current 35 A
Battery temperature sensor Yes
Programmable relay (5) Yes
Protection (2) a - g
VE.Bus communication port For parallel and three phase operation, remote monitoring and system integration
General purpose com. port Yes, 2x
Model MPPT 250/70-Tr
Maximum output current 70 A
Maximum PV power 4000 W
Maximum PV open circuit voltage 250 V
Maximum efficiency 99%
Self-consumption 20 mA
Charge voltage 'absorption', default 57,6 V
Charge voltage 'float', default 55,2 V
Protection (2) a – e
Interfaces BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi
Remote on-off Yes
Operating temp. range -20 to +45 °C (fan assisted cooling) Max. altitude 2000 m
Humidity (non-condensing): max 95 %
Material & Colour aluminium (blue RAL 5012)
Protection category IP21
Battery-connection M8 bolts
PV connection M6 bolts
230 VAC-connection Screw terminals 16 mm2 (6 AWG)
Safety EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission / Immunity EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3
IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Anti-islanding See our website
Warranty 5 years / extensions up to 10
