The Victron Energy Orion-Tr 24/12-9 (110W) is an isolated DC-DC converter designed to convert power from a nominal 24V DC source to an adjustable 12V-class DC output. This model operates across a 16–35V DC input range, provides a nominal 12.2V output, and delivers 9A continuous output current at nominal output voltage and 25°C.

Designed for applications requiring electrical separation between DC circuits, the Orion-Tr provides 200V DC galvanic isolation between input, output, and case. It also features remote on/off control, short-circuit protection, high-temperature protection, adjustable output voltage, parallel operation capability, and screw-terminal connections. Victron specifically states that this converter is not intended for battery charging.

Key Technology

• 24V-to-12V Isolated DC Conversion
  Designed to provide an adjustable 12V-class DC supply from a nominal 24V source while maintaining galvanic separation between the input and output circuits.

• 200V DC Galvanic Isolation
  Provides electrical isolation between the input, output, and case, making the converter suitable for applications where galvanic separation is required.

• Adjustable Output Voltage
  The output can be adjusted from 10V to 15V DC, allowing the converter to accommodate compatible equipment requiring different regulated DC supply voltages.

• 9A Continuous Output
  Provides 9A continuous output current at nominal output voltage and 25°C, with additional short-duration output capability for compatible loads.

• Remote On/Off Control
  The remote terminal eliminates the need for a high-current switch in the input wiring and can instead be operated by a suitable low-power switch or control signal.

• Short-Circuit Protection
  Designed with short-circuit protection to help protect the converter during abnormal output conditions.

• Parallel Operation
  Victron allows multiple compatible Orion-Tr converters to be connected in parallel when additional output-current capacity is required.

• High-Temperature Protection
  The converter reduces output current at elevated ambient temperatures to protect its internal power electronics.

• IP43 Protection
  Provides IP43 protection when installed with the screw terminals oriented downward as specified by Victron.

Best Uses

• 24V Battery-Based Systems
  Suitable for powering compatible 12V-class equipment from a properly configured 24V DC electrical system.

• Isolated Auxiliary DC Circuits
  Ideal when a lower-voltage auxiliary circuit needs galvanic separation from the primary DC supply.

• Vehicle Electrical Systems
  Suitable for compatible automotive and mobile installations requiring an isolated DC supply from a 24V source.

• Marine DC Systems
  Useful for compatible onboard DC equipment where electrical separation between source and load circuits is required.

• Off-Grid Power Systems
  Provides isolated DC conversion for compatible auxiliary loads within battery-based solar and standalone power systems.

• Controls & DC Electronics
  Suitable for compatible controls, communications equipment, electronics, and other equipment requiring a regulated 12V-class DC supply.

Product Specifications

Isolated & Adjustable 24V-to-12V DC Power Conversion

The Victron Energy Orion-Tr 24/12-9 (110W) Isolated DC-DC Converter combines galvanic isolation, adjustable output voltage, remote on/off control, parallel operation, and integrated protection in a dependable DC conversion solution. It is well suited for properly configured 24V electrical systems that require an isolated and regulated 12V-class auxiliary power supply.
