Victron Energy LiNGST Lithium NG Service Tool USB-C ASS032300030

The Victron Energy ASS032300030 LiNGST Lithium NG Service Tool USB-C is a professional diagnostic and commissioning interface designed to provide a direct wired connection between a Windows PC and the M8 service connector on compatible Victron Lithium NG batteries and BMS NG products. It gives trained installers and service personnel access to advanced battery monitoring, data logging, BMS testing, troubleshooting, and commissioning functions.

The ASS032300030 is specifically the USB-C version of the Lithium NG Service Tool. It incorporates a 150 cm (59.1 in) USB cable and a 20 cm (7.9 in) M8 connector lead. The product-variant section and image on page 2 of the manual distinguish this model from the USB-A version, ASS032300010.

Using the Victron Lithium NG Service Tool application for Windows, technicians can monitor and log Lithium NG battery data, simulate a Lithium NG battery to test BMS functionality, and record data from complete multi-battery Lithium NG systems.

The LiNGST is a tool for commissioning, debugging, in-depth system analysis, and technical assistance during on-site work, particularly where wireless access is unavailable.

Key Technology

• USB-C Lithium NG Service Interface
  Part number ASS032300030 is the USB-C version of Victron's LiNGST, providing a direct wired interface between a compatible Windows PC and Lithium NG equipment.

• Direct M8 Service Connection
  Connects to the M8 service connector on supported Victron Lithium NG batteries and BMS NG products for direct diagnostic communication.

• Battery Monitoring & Logging
  The Battery Tester function allows technicians to monitor and record operating data from connected Lithium NG batteries, including cell-level information and diagnostic identifiers.

• Lithium NG Battery Emulation
  The BMS Tester can simulate a Lithium NG battery, allowing technicians to inspect BMS functionality without requiring a physical Lithium NG battery during the test.

• BMS Function Testing
  Supports inspection of external BMS functions including ATD, ATC, Pre-alarm, and relay status, making the tool useful for commissioning and troubleshooting.

• Multi-Battery Data Sniffer
  The Data Sniffer function provides monitoring and logging for systems where multiple Lithium NG batteries are connected in a daisy chain.

• Adjustable Battery Emulator
  During BMS testing, simulated battery current, individual cell voltage, and individual cell temperature can be adjusted through the software interface.

• Diagnostic System Information
  Provides access to data such as serial number, firmware, Product ID, and BootLoader information, which can be useful when working with technical support.

• 150 cm USB Cable
  The USB-C version uses a 150 cm (approximately 4.9 ft) USB cable, providing convenient reach between the service computer and battery installation.

• 20 cm M8 Connector Lead
  Includes a 20 cm (approximately 7.9 in) M8 connector lead for connection to supported Lithium NG batteries and BMS equipment.

Best Uses

• Lithium NG Battery Commissioning
  Designed for professional commissioning of compatible Victron Lithium NG battery installations.

• Battery Diagnostics
  Allows technicians to view and record detailed Lithium NG battery information when troubleshooting system operation.

• BMS NG Testing
  Ideal for inspecting supported BMS functionality using the integrated Lithium NG battery emulator.

• Multi-Battery System Troubleshooting
  The Data Sniffer function is designed for live viewing and recording of battery data across a complete daisy-chained Lithium NG battery system.

• On-Site Technical Support
  Provides a direct wired diagnostic connection for installation and support situations where wireless access is unavailable or unsuitable.

• Professional Service Personnel
  Victron specifies that the tool is intended for trained installers and service personnel only because it provides access to diagnostic and commissioning functions beyond standard user-accessible information.

Product Specifications

Professional USB-C Diagnostics for Victron Lithium NG Systems

The Victron Energy ASS032300030 LiNGST Lithium NG Service Tool USB-C provides trained technicians with a direct wired solution for Lithium NG battery monitoring, data logging, BMS testing, battery emulation, multi-battery diagnostics, commissioning, and troubleshooting. Its USB-C computer interface, M8 service connection, Windows software support, and advanced diagnostic capabilities make it a specialized service tool for the Victron Lithium NG ecosystem.
