Victron Energy Cyrix-Li-Charge 24/48V 120A Intelligent Charge Relay CYR020120430

The Victron Energy CYR020120430 Cyrix-Li-Charge 24/48-120 is a 120A intelligent charge relay designed for compatible lithium battery systems using a VE.Bus BMS. It provides BMS-controlled connection and disconnection of a battery charger, helping protect LiFePO4 battery cells against overvoltage and excessive temperature conditions.

The Cyrix-Li-Charge 24/48-120 supports 24V and 48V battery systems. It provides a 120 A continuous current and breaking capacity at 24V and a 40A breaking capacity at 48V. The relay responds to both its BMS control input and voltage detected at the charger and battery terminals.

Key Technology

• 120A Intelligent Charge Relay
  Provides a high-current switching interface between a compatible battery charger and lithium battery system, with a continuous-current rating of 120A.

• 24V / 48V System Compatibility
  The Cyrix-Li-Charge 24/48-120 is specifically configured for compatible 24V and 48V LiFePO4 battery systems.

• VE.Bus BMS Controlled
  Uses the Charge Disconnect output from a compatible VE.Bus BMS to determine whether charging is permitted.

• Automatic Charger Connection
  The relay connects the battery charger after a 3-second delay when the BMS permits charging and the required charger and battery voltage conditions are satisfied.

• Automatic Overvoltage Protection
  The Cyrix-Li-Charge immediately disconnects when its control input becomes free-floating, indicating a cell-overvoltage or cell-overtemperature condition.

• Voltage-Sensing Operation
  For this 24/48V version, charger connection is based on sensing approximately 27.4V for a 24V system or 54.8V for a 48V system at the charger terminal, along with at least 2V at the battery terminal.

• Automatic Reconnection Logic
  Following a cell-overvoltage event, the Cyrix can reconnect the charger after a 3-second delay once conditions recover. After two unsuccessful re-engagement attempts, the delay increases to 10 minutes.

• Low-Voltage Disconnect Logic
  If battery voltage falls below approximately 27V in a 24V system or 54V in a 48V system, the Cyrix-Li-Charge disengages after a one-hour delay.

• Low Standby Consumption
  Consumes less than 4 mA when open, helping minimize unnecessary battery drain.

• Compact IP54 Enclosure
  The compact relay measures only 46 × 46 × 80 mm and carries an IP54 protection rating.

Best Uses

• 24V LiFePO4 Battery Systems
  Suitable for compatible 24V lithium battery installations requiring BMS-controlled charger isolation.

• 48V LiFePO4 Battery Systems
  Designed to provide the same intelligent charging-control functionality in compatible 48V battery systems.

• VE.Bus BMS Installations
  Ideal when a battery charger cannot be directly switched or controlled by the VE.Bus BMS.

• Battery Charger Protection
  Provides automatic charger isolation when the BMS detects battery conditions that require charging to stop.

• Marine & Mobile Power Systems
  Suitable for compatible marine, RV, vehicle, and other battery-based electrical systems requiring controlled lithium charging.

• Battery-Based Energy Systems
  Provides a compact high-current relay interface for appropriately designed lithium battery and charging installations.

Product Specifications

Intelligent 120A Charger Control for 24V & 48V Lithium Systems

The Victron Energy CYR020120430 Cyrix-Li-Charge 24/48-120 provides a compact solution for integrating battery chargers with VE.Bus BMS-controlled LiFePO4 systems. With its 120A continuous-current capability, 24/48V operation, automatic voltage sensing, immediate BMS-controlled disconnection, intelligent reconnection logic, low standby consumption, and compact IP54 enclosure, it provides reliable charger switching and battery protection in compatible lithium energy systems.
