The Victron Energy Argo Diode Battery Isolator 80-2SC is designed to allow two batteries to be charged simultaneously from a single alternator without directly connecting the batteries together. This helps keep separate battery banks electrically independent during discharge, so using an accessory battery does not also discharge the starter battery.

The ARG080201000 model supports a maximum charge current of 80A and a maximum alternator current of 80A. It uses Schottky diodes to minimize voltage loss and incorporates a compensation diode that can be used to help compensate for the voltage drop introduced by the isolator.

Key Technology

• Two-Battery Isolation
  Allows two battery banks to receive charging current from one alternator while keeping the batteries separated from one another during discharge.

• 80A Charge Current Rating
  Designed for a maximum charge current of 80A and a maximum alternator current of 80A.

• Schottky Diode Technology
  Uses Schottky diodes to reduce the voltage drop normally associated with diode-based battery isolation.

• Low Voltage Drop
  Victron specifies an approximate voltage drop of 0.3V at low current and approximately 0.45V at rated output.

• Compensation Diode
  An integrated compensation diode can be used to slightly increase alternator output voltage, helping compensate for voltage loss across the isolator's diodes.

• Independent Battery Discharge
  Because the battery banks remain isolated, discharging an accessory battery does not automatically discharge the starter battery.

• M6 Stud Connections
  Uses robust M6 stud connections for the main high-current alternator and battery connections.

• Passive Battery Isolation
  Provides diode-based battery-bank separation without requiring the batteries to be directly paralleled during normal operation.

Best Uses

• Starter & Auxiliary Battery Systems
  Ideal for systems where one alternator needs to charge both a starter battery and a separate auxiliary battery.

• Vehicle Dual-Battery Systems
  Suitable for compatible vehicle electrical systems where accessory loads should remain separated from the starter battery.

• Marine Battery Systems
  Useful in properly configured onboard electrical systems with separate starting and auxiliary battery banks charged from a common alternator.

• RV & Mobile Power Systems
  Suitable for systems where a starter battery and a separate house or accessory battery require charging from the vehicle alternator.

• Equipment with Separate Battery Banks
  Provides a straightforward method of alternator charging where two compatible battery banks must remain isolated during discharge.

Product Specifications

Reliable Two-Battery Isolation from a Single Alternator

The Victron Energy Argo Diode Battery Isolator 80-2SC provides a straightforward solution for charging two separate battery banks from one compatible alternator while preventing the batteries from directly discharging into one another. With Schottky diode technology, low voltage drop, a compensation diode, and robust stud connections, it is well suited to properly designed dual-battery DC electrical systems.
