Victron Energy ANL-fuse 500A/80V (Package of 5 pcs) Fuse CIP143500020

The Victron Energy CIP143500020 ANL-Fuse is a high-current 500A, 80V DC fuse designed to provide overcurrent protection for compatible battery and DC electrical systems. Its ANL bolt-down format provides a secure and serviceable protection solution for circuits carrying substantial DC current.

With a 500A current rating and 80V DC rating, this fuse is suited to appropriately engineered battery banks, inverter connections, and high-current DC distribution circuits. Victron Energy's current documentation identifies CIP143500020 as the ANL-fuse 500A/80V model.

Package Quantity: Five (5) Victron Energy ANL-Fuse 500A/80V fuses.

Key Technology

• 500A Current Rating
  Provides 500-amp overcurrent protection for compatible high-current DC circuits when properly selected according to conductor ampacity, equipment requirements, and overall system design.

• 80V DC Rating
  Rated for circuits operating at up to 80V DC, providing suitable voltage capability for appropriately designed low-voltage battery and DC power systems.

• ANL Fuse Format
  Uses a high-current ANL fuse design with a bolt-down electrical interface for secure installation in compatible DC circuit-protection equipment.

• Fast-Acting Protection
  Victron ANL fuses are specified as fast-acting and provide a higher short-circuit breaking capability than MEGA fuses, making the format suitable for demanding high-current DC protection applications.

• Approx. 125mV Voltage Drop
  The 500A model is specified with an approximate 125mV voltage drop under its specified operating conditions.

• Low Cold Resistance
  Specified with approximately 0.25mΩ cold resistance, supporting efficient integration into properly designed high-current DC circuits.

• Replaceable Overcurrent Protection
  Provides a replaceable protective element designed to interrupt excessive current and help protect properly sized conductors and connected DC equipment.

• Dedicated ANL Fuse Holder Compatibility
  Victron Energy lists the CIP106100000 Fuse Holder for ANL-Fuse alongside its ANL fuse range for compatible installations.

Best Uses

• 48V Battery Systems
  Suitable for appropriately engineered 48V battery systems requiring high-current 500A circuit protection. The 80V DC rating provides compatibility with properly designed 48V battery circuits operating within the fuse's voltage limit.

• High-Capacity Battery Banks
  Suitable for protecting properly sized conductors associated with battery banks capable of supplying substantial DC current.

• Solar & Energy Storage Systems
  Can be incorporated into appropriately engineered solar and battery-storage DC circuits where system design specifies a 500A ANL fuse.

• High-Power Inverter Circuits
  Suitable for compatible inverter and inverter/charger DC input circuits when equipment requirements and conductor sizing call for 500A overcurrent protection.

• Battery-to-Busbar Connections
  Provides a high-current protective device for appropriately designed battery-to-busbar and related DC distribution connections.

• High-Current DC Distribution
  Suitable for DC distribution circuits where connected equipment, conductors, and system protection requirements specify a 500A fuse.

Product Specifications

High-Current 500A Protection for DC Power Systems

The Victron Energy CIP143500020 ANL-Fuse 500A/80V provides robust, replaceable overcurrent protection for compatible high-current DC electrical systems. Its 500A rating, 80V DC capability, fast-acting ANL construction, and high short-circuit breaking capability make it a practical protection component for appropriately engineered battery, inverter, charging, and DC distribution circuits.
