Solis 60kW Three Phase Hybrid 480Vac 1000V Four MPPT
S6-EH3P60K04-NV-YD-H-US
The Solis S6-EH3P60K04-NV-YD-H-US is a high-performance three-phase hybrid inverter designed for advanced energy storage and grid-interactive applications.
Supporting both DC and AC coupling, this inverter enables flexible system design, seamless retrofits, and efficient energy management across solar, battery, and generator inputs.
Key Technology
-
Hybrid AC/DC Coupling
Supports both DC and AC coupling for flexible system expansion and retrofit applications. -
Fast Backup Switching
Achieves seamless on-grid to off-grid transition in less than 10 ms for uninterrupted power supply. -
High PV Input Capacity
Supports up to 100 kW PV input with 21A string current compatibility for modern high-power modules. -
Dual Battery Ports
Two independent battery inputs allow flexible configuration and easy system expansion. -
Generator Integration
Seamlessly integrates with generators for reliable operation in weak-grid or backup scenarios. -
High Overload Capability
Delivers up to 160% overload for 2 seconds in off-grid mode to support heavy load startup. -
Smart Monitoring
SolisCloud platform enables remote monitoring, AI optimization, and real-time diagnostics.
Best Uses
-
Energy Storage Systems
Integrates solar and battery storage for optimized energy usage and backup power. -
Grid-Tied with Backup
Provides uninterrupted power with seamless transition during outages. -
Hybrid Power Systems
Supports solar, battery, and generator integration in a single platform.
Warranty
- Warranty: 10 years (standard manufacturer warranty)
Product Specifications
| Specification | Details |
|---|---|
| Manufacturer | Solis |
| Model | S6-EH3P60K04-NV-YD-H-US |
| Inverter Type | Three-Phase Hybrid (High Voltage) |
| Rated Output Power | 60 kW |
| Max PV Input Power | 100 kW |
| Max Efficiency | 97.9% |
| CEC Efficiency | 97.4% |
| MPPT Efficiency | 99.9% |
| MPPT Voltage Range | 150 – 850 V |
| Max Input Voltage | 1000 V |
| Battery Type | Li-ion |
| Battery Voltage Range | 150 – 800 V |
| Max Charge / Discharge Power | 60 kW |
| Battery Ports | 2 |
| Grid Voltage | 480 V (3-phase) |
| Frequency | 60 Hz |
| Max Output Current | 72.2 A |
| Power Factor | >0.99 |
| Switch Time (Backup) | <10 ms |
| Dimensions | 22.05 × 41.34 × 13.64 in |
| Weight | 195.77 lbs |
| Cooling | Intelligent fan cooling |
| Protection Rating | Type 4X |
| Communication | CAN, RS485, Ethernet, Optional WiFi/Cellular |
| Monitoring | SolisCloud Platform |
| Max Parallel Operation | Up to 600 kW |
About Solis:
Solis is a global manufacturer of high-performance solar inverters and energy storage solutions. Known for innovation, reliability, and advanced monitoring capabilities, Solis delivers scalable solutions for residential, commercial, and large-scale energy systems worldwide.
Advanced Hybrid Power Management for Reliable Energy Systems
The Solis S6-EH3P60K04-NV-YD-H-US combines high PV input capacity, fast switching, and intelligent energy management to deliver flexible, efficient, and reliable hybrid energy solutions.
