Solectria CR1500-28P-20F-400S 1500VDC Combiner 28 Fuse NEMA 4 400A
CR1500-28P-20F-400S
Solectria CR1500-28P-20F-400S 1500VDC Combiner 28 Fuse NEMA 4 400A
Key Features
- Seamless Compatibility: Specifically designed for SOLECTRIA XGI 1500-166 and XGI 1500-250 series inverters.
- Expanded Fuse Capacity: Equipped with 28 fuse positions, each rated at 20 A, enabling flexible system configurations.
- Voltage and Current Capacity: Operates up to 1500 VDC with a robust 400 A DC disconnect switch for reliable and efficient power handling.
- Safety-Integrated Design: Standard surge protection for both positive and negative poles to enhance system reliability.
- Rugged Construction: Polyester powder-coated steel enclosure with NEMA 4 rating ensures durability in outdoor and harsh environments.
- Compliance and Certification: UL 1741 certified and adherent to the Buy American Act (BAA), meeting both safety and domestic manufacturing standards.
Applications
- Ideal for centralized and distributed PV systems requiring NEC compliance.
- Suitable for utility-scale and commercial solar installations prioritizing reliability and safety.
Installation
- Flexible Mounting Options: Can be mounted vertically, horizontally, or at an angle on walls or array structures.
- Environmental Durability: Designed to operate efficiently in extreme temperature ranges from -40°F to 140°F (-40°C to +60°C), suitable for various climates.
Specifications
Feature | Details |
---|---|
Model | CR1500-28P-20F-400S |
Fuse Configuration | Positive polarity fused |
Voltage Rating | 1500 VDC |
Disconnect Switch Rating | 400 A |
Fuse Positions | 28 |
Fuse Rating | 20 A |
Surge Protection | Standard, both polarities |
Enclosure Material | Polyester powder-coated steel, NEMA 4 |
Weight | Approximately 80 lb |
Dimensions (HxWxD) | 30 in. x 24 in. x 8 in. |
Certifications | UL 1741 |
Warranty | 5 years |
Why Choose Solectria Inverters?
Solectria, a Yaskawa company, is a leading manufacturer of high-quality inverters for residential, commercial, and utility-scale solar applications. Renowned for their advanced technology, Solectria inverters are designed to enhance energy efficiency and ensure long-term performance.
Products such as the Solectria PVI and XGI series feature innovative grid-support capabilities and wide operating voltage ranges, providing flexibility and reliability for various project needs. Offering a generous 10-year warranty, with options to extend, Solectria stands behind the durability and craftsmanship of their inverters.
Domestic Added Content Bonus Eligibility
Solectria offers several inverter models that qualify for the Domestic Added Content Bonus, ensuring customers can benefit from both superior performance and added cost savings. Among these models, the Solectria XGI 1000 and XGI 1500 series stand out, designed with high percentages of domestically sourced components.
These inverters not only deliver exceptional efficiency and reliability but also contribute significantly to the support of local manufacturing industries. By selecting these eligible models, customers are able to secure additional financial incentives while benefiting from advanced solar technology that adheres to rigorous quality standards.
