Solectria Fused String Combiner CR1500-16P-20F-400S 1500VDC 400A NEMA4
Solectria Fused String Combiner CR1500-16P-20F-400S 1500VDC 400A NEMA4
Solectria Fused String Combiner CR1500-16P-20F-400S 1500VDC 400A NEMA4
Solectria Fused String Combiner CR1500-16P-20F-400S 1500VDC 400A NEMA4
Delivery
Shipping disclaimer: US Solar Supplier works hard to offer the most competitive shipping rates possible. Shipping is auto calculated. If you have questions, let's work together directly! Please reach out to arrange case based logistics. Contact our team at sales@ussolarsupplier.com or by chat during business hours 9 am to 5 pm EST.
Payment
We offer multiple secure payment options for your convenience
Solectria Fused String Combiner CR1500-16P-20F-400S 1500VDC 400A NEMA4
CR1500-16P-20F-400S
Solectria Fused String Combiner CR1500-16P-20F-400S 1500VDC 400A NEMA4
Key Features
- Compatibility: Designed specifically for SOLECTRIA XGI 1500-166 and XGI 1500-250 series inverters.
- Fuse Configuration: Includes 16 fuse positions, each rated for 20 A, suitable for scalable PV systems.
- Voltage and Current Ratings: Handles up to 1500 VDC with a robust 400 A DC disconnect switch for efficient current management.
- Surge Protection: Equipped with standard surge protection on both positive and negative poles to ensure system safety.
- Durable Construction: Made from polyester powder-coated steel, rated NEMA 4 for protection in outdoor environments.
- Certified and Compliant: UL 1741 certified for safety and performance and fully compliant with the Buy American Act (BAA).
Applications
- Centralized and distributed PV systems requiring NEC-compliant solutions.
- Large commercial and utility-scale solar installations prioritizing high reliability and robust safety features.
Installation
- Mounting Options: Flexible installation on walls or array structures, supporting vertical, horizontal, or angled orientations.
- Environmental Tolerance: Operates in extreme temperatures ranging from -40°F to 140°F (-40°C to +60°C), ensuring consistent performance in various climates.
Specifications
| Feature | Details |
|---|---|
| Model | CR1500-16P-20F-400S |
| Fuse Configuration | Positive polarity fused |
| Voltage Rating | 1500 VDC |
| Disconnect Switch Rating | 400 A |
| Fuse Positions | 16 |
| Fuse Rating | 20 A |
| Surge Protection | Standard, both polarities |
| Enclosure Material | Polyester powder-coated steel, NEMA 4 |
| Weight | Approximately 80 lb |
| Dimensions (HxWxD) | 30 in. x 24 in. x 8 in. |
| Certifications | UL 1741 |
| Warranty | 5 years |
Why Choose Solectria Inverters?
Solectria, a Yaskawa company, is a leading manufacturer of high-quality inverters for residential, commercial, and utility-scale solar applications. Renowned for their advanced technology, Solectria inverters are designed to enhance energy efficiency and ensure long-term performance.
Products such as the Solectria PVI and XGI series feature innovative grid-support capabilities and wide operating voltage ranges, providing flexibility and reliability for various project needs. Offering a generous 10-year warranty, with options to extend, Solectria stands behind the durability and craftsmanship of their inverters.
Domestic Added Content Bonus Eligibility
Solectria offers several inverter models that qualify for the Domestic Added Content Bonus, ensuring customers can benefit from both superior performance and added cost savings. Among these models, the Solectria XGI 1000 and XGI 1500 series stand out, designed with high percentages of domestically sourced components.
These inverters not only deliver exceptional efficiency and reliability but also contribute significantly to the support of local manufacturing industries. By selecting these eligible models, customers are able to secure additional financial incentives while benefiting from advanced solar technology that adheres to rigorous quality standards.
