SolarEdge SE14.4K-USR28BNU4 14.4-US w/AC RSD three phase 208v

SolarEdge SE14.4K-USR28BNU4 14.4-US w/AC RSD three phase 208v

$3,513.77
$3,513.77
SolarEdge

SolarEdge SE14.4K-USR28BNU4 14.4-US w/AC RSD three phase 208v

SolarEdge SE14.4K-USR28BNU4 14.4-US w/AC RSD three phase 208v

No reviews
$3,513.77
$3,513.77
View full details
Description
Questions
Reviews
SolarEdge
Manufacturer
SolarEdge
Weight
106 lb
Dimension
(LxWxH): 30.5 x 12.5 x 10.5 Inches
SolarEdge SE14.4K-USR28BNU4 14.4-US w/AC RSD three phase 208v

SolarEdge Inverter System is a all-in-one system that includes an inverter, charger controller, a display with remote monitoring. The Sol-Ark is simple to install to a Grid-tied, Off-Grid, or Battery Backup solar system, while being able to manages power to and from Solar, Battery, Grid, Loads, and Generator.


SPECIFICATIONS

Model SolarEdge SE14.4K-USR28BNU4
Series Energy Hub
Manufacturer SolarEdge


ELECTRICAL DATA - OUTPUT

Nominal Output Power 14,400 V
Voltage 208 VAC
AC Output Line Connections 4-wire WYE (L1-L2-L3-N) plus PE or 3 wire Delta
AC Output Voltage Minimum-Nominal-Maximum (2) for North America (L-N) 105-120-132.5 VAC
AC Output Voltage Minimum-Nominal-Maximum (2) (L-L) 183-208-229 VAC
Frequency 59.3 - 60 - 60.5 Hz
Max. Continuous Output Current (per Phase) 40 A


ELECTRICAL DATA - OUTPUT

Maximum DC Power (STC) 19400 W
Transformer-less, Ungrounded Yes
Maximum Input Voltage DC to Ground 300 V
Maximum Input Voltage DC+ to DC- 600 V
Nominal Input Voltage DC to Ground 200 V
Nominal Input Voltage DC+ to DC- 400 V
Max Input Current 38 ADC


Warranty

  • Manufacturer Warranty 12 Years

* Refer to warranty document for terms and conditions

Documentation

Data Sheet


Detailed Information

SolarEdge three phase inverter combines sophisticated digital control technology with efficient power conversion architecture to achieve superior solar power harvesting and best-in-class reliability. The fixed-voltage technology ensures the solar inverter is always working at its optimal input voltage over a wider range of string lengths and regardless of environmental conditions

High reliability

Cell interconnections and diode placement use well-established industry practice and are field-proven to provide excellent reliability.

Small, lightweight, and easy to install

Quality and certifications

UL1741, UL1741 SA, UL1699B, CSA C22.2, Canadian AFCI according to T.I.L. M-07

IEEE1547, Rule 21 , Rule 14(HI)
