SolarEdge Power Optimizer 650W 15A 60V U650-1GM4MRMU Domestic Content
U650-1GM4MRMU
Specifications
SolarEdge Power Optimizer 650W 15A 60V U650-1GM4MRMU Domestic Content
Key Features
- Module-Level Power Optimization: Enhances energy yield by mitigating mismatch losses due to shading, soiling, and manufacturing tolerances.
- Superior Efficiency: Achieves up to 99.5% maximum efficiency and 98.6% weighted efficiency.
- Advanced Safety: Includes patented SafeDC™ for module-level voltage shutdown, ensuring installer and firefighter safety. Features Sense Connect technology to detect and prevent potential electrical arcs.
- NEC Compliance: Meets NEC 2014–2023 requirements for rapid shutdown and arc fault protection.
- Easy Installation: Simplified cable management with a single-bolt assembly for faster deployment.
- Wide Compatibility: Supports high-powered and bifacial PV modules with up to 60V input voltage and 15A maximum input current.
Applications
- Designed for residential PV installations with SolarEdge inverters.
- Ideal for systems with high-power modules or bifacial modules.
- Suitable for areas requiring advanced safety standards and rapid shutdown compliance.
Installation
- Compact and Lightweight Design: Simplifies installation and reduces handling time.
- Connector Type: Compatible with MC4 connectors for input and output.
- Environmental Protection: Rated IP68 for reliable performance in harsh conditions, including dust and water immersion.
Specifications
| Parameter | Value |
|---|---|
| Model | SolarEdge U650 |
| Rated Input DC Power | 650 W |
| Maximum Input Voltage (Voc) | 60 V |
| MPPT Operating Range | 8–60 V |
| Maximum Input Current (Isc) | 15 A |
| Maximum Input Short Circuit Current | 18.75 A |
| Maximum Efficiency | 99.5% |
| Weighted Efficiency | 98.6% |
| Maximum Output Voltage | 60 V |
| Maximum Output Current | 15 A |
| Dimensions | 5.07 × 6.10 × 1.18 in |
| Weight | 1.6 lbs |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP68 / NEMA6P |
| Connector Type | MC4 |
| Warranty | 25 years |
Why SolarEdge?
SolarEdge is a global leader in smart energy technology, renowned for its innovative approaches to power management. Founded in 2006 in Israel but headquarter in California, the company has been at the forefront of solar energy solutions for over 17 years. SolarEdge specializes in a wide range of products, including solar inverters, power optimizers, and a comprehensive suite of monitoring and smart energy management solutions.
One of the defining technologies of SolarEdge is its power optimizer, which maximizes energy output from each solar panel through constant tracking of maximum power points. This allows for increased energy yield and improved system operation.
SolarEdge products come with a warranty that demonstrates their commitment to quality and customer satisfaction. Typically, their inverters come with a standard warranty of 12 to 25 years, while power optimizers usually carry a 25-year warranty.
