SMA Sunny Boy 7.7-US Standard with integrated DC disco, 3-MPPT, AFCI 208/240VAC

SMA Sunny Boy 7.7-US Standard with integrated DC disco, 3-MPPT, AFCI 208/240VAC

Regular price $1,811.38
Sale price $1,811.38 Regular price
SOLD OUT
No reviews
Leave a Review

MPN No: SB 7.7-1SP-US-41

SMA Sunny Boy 7.7-US Standard with integrated DC disco, 3-MPPT, AFCI 208/240VAC

SMA Sunny Boy 7.7-US Standard with integrated DC disco, 3-MPPT, AFCI 208/240VAC

No reviews
Leave a Review
Regular price $1,811.38
Sale price $1,811.38 Regular price

View full details
Description
Questions
Reviews
Default manufacturer logo
Manufacturer
SMA Solar
SMA
Sunny Boy US-41
Transformerless Grid Tie Inverters
w/SunSpec Rapid Shutdown
The latest and greatest versions of the SMA Sunny Boy Transformerless Inverters (-US-41) offer integrated SunSpec-compliant technology. It fulfills UL 1741, NEC 2014, and NEC 2017 requirements and is compatible with the power line-based SunSpec Rapid Shutdown communication signal over DC wires, making it the most simple and cost-effective rapid shutdown solution on the market.

*NOTE: SMA is having component issues around the Wifi features of their inverters. See DOCUMENTS tab for official statement and options available. In the interim, the V2 versions listed above will be shipped that do NOT have the integrated Wifi functionality. Installers may still use ethernet (wired) communications for commissioning and operation.
FEATURES
NEW! SunSpec certified inverter technology in conjunction with the TS4-R-F, which gives PV installers a more cost-effective way to achieve compliance with NEC 2017 module-level shutdown
Advanced AFCI compliant to new Standard UL 1699B Ed.1 for arc fault protection – delivering improved safety and reliability while allowing for automatic resetting
New Installation Assistant with direct access via smartphone minimizes time in the field
SMA Smart Connected will automatically detect errors and initiate the repair and replacement process so that installers can reduce service calls
Integrated wall mount bracket speeds up installation time
Less components - Rooftop Communication Kit is NOT needed with TS4-R-F unit + SB-41 Inverter
Secure Power Supply (SPS) included
SPS is NOT compatible with the SunSpec Rapid Shutdown functionality so will not function if TS4-R-F is in use. Only functions with the TS4-R-O unit.
DC disconnect integrated in - speeds up installation time, and only 1 box to ship
Connect to user interface either with Ethernet Cable or Wirelessly (WLAN)
Broad voltage range enables production under a variety of conditions
Extended operating temperature range allows for extended daily production
Two or Three MPP trackers (depending on the model - see table) provide numerous design options for complex roofs
Transformerless topology results in lighter weight and higher efficiency
Free Sunny Portal monitoring with global access
Large informative graphic display for easy viewing
10 Year Warranty - extendable to 15 or 20 years
SPECIFICATIONS
