Sigenergy SigenMicro 768W Dual-Module Solar Microinverter

240V Grid-Tied Microinverter with Dual MPPT, WLAN Mesh and Module-Level Monitoring

768W AC Output | 2 Solar Panel Inputs | 2 MPPT Trackers | 97.5% Maximum Efficiency
The Sigenergy SigenMicro 768 US is a high-efficiency, dual-module solar microinverter designed to convert DC electricity from two solar panels into grid-compatible 240V AC power. Featuring independent maximum power point tracking, built-in WLAN Mesh communication, and intelligent module-level monitoring, the SigenMicro 768 delivers efficient energy production with streamlined installation and advanced system management.

Product Highlights

• 768W maximum continuous AC output: High-output microinverter for two solar panels.
• Dual solar panel inputs: Connects two compatible PV modules.
• Independent MPPT tracking: Optimizes each connected solar panel individually.
• 97.5% maximum efficiency: High-efficiency solar power conversion.
• 240V AC output: Designed for compatible grid-tied solar installations.
• 16–60V MPPT operating range: Supports a wide range of modern solar panels.
• 16A maximum input current per channel: Supports compatible high-current PV modules.
• WLAN Mesh communication: Enables reliable wireless communication between microinverters.
• Integrated energy management: Supports intelligent monitoring without a separate network gateway.
• Module-level monitoring: View performance information for connected solar panels.
• Rapid shutdown support: Designed for compliant rooftop solar system integration.
• NEMA Type 6 enclosure: Durable construction for outdoor solar applications.

Manufacturer: Sigenergy

Model: SigenMicro 768 US

Product Type: Dual-Module Grid-Tied Solar Microinverter

High-Efficiency Solar Power Conversion for Two Panels

The Sigenergy SigenMicro 768 US provides an efficient solution for residential solar installations using module-level power electronics.

Unlike a traditional string inverter that manages multiple panels together, the SigenMicro converts solar energy into AC electricity directly at the module level.

Each SigenMicro 768 connects to two compatible solar panels, reducing the number of microinverters needed for a given array while maintaining independent performance tracking for each module.

With up to 768W of continuous AC output, the microinverter is designed to work with modern solar panels and deliver reliable energy production throughout changing sunlight conditions.

Its compact design, outdoor-rated enclosure, and integrated communication capabilities make it well suited for residential rooftop solar installations and other compatible grid-connected applications.

Dual MPPT for Independent Solar Panel Optimization

The SigenMicro 768 features two independent maximum power point trackers, allowing each connected solar panel to operate at its own optimal electrical conditions.

Dual MPPT Benefits

• Individual panel optimization: Each solar module is tracked independently.
• Improved performance under variable sunlight: Helps manage differences in solar panel production.
• Flexible array design: Supports compatible modules installed in different orientations.
• Reduced mismatch losses: Limits the impact of differences between connected panels.
• Module-level visibility: Monitor individual solar panel performance.

Independent MPPT tracking is particularly useful for residential solar arrays where roof angles, shading, or panel operating conditions may vary.

Built-In WLAN Mesh Communication

The Sigenergy SigenMicro series features integrated WLAN Mesh communication technology designed to simplify monitoring and system connectivity.

Microinverters communicate through a wireless mesh network, creating a scalable communication architecture for larger solar arrays.

Smart Monitoring Features

• WLAN Mesh networking: Supports wireless communication between microinverters.
• Integrated energy management: Designed to eliminate the need for a separate network gateway.
• Module-level monitoring: Track performance of individual connected solar panels.
• Intelligent system commissioning: Supports streamlined setup through Sigenergy's monitoring platform.
• AI-assisted layout recognition: Helps identify connected module locations during system setup.
• Whitelisting security: Provides additional communication and system access protection.

These features provide installers and homeowners with detailed visibility into solar production and system performance.

Advanced Solar Microinverter Technology

The SigenMicro 768 incorporates Sigenergy's innovative Dual Active Bridge (DAB) power conversion topology.

This architecture is designed to deliver high conversion efficiency while maintaining compact dimensions and reliable performance.

Technology Advantages

• Up to 97.5% maximum conversion efficiency.
• High-frequency transformer design with galvanic isolation.
• Independent power tracking for two PV modules.
• Natural convection cooling without mechanical fans.
• Compact bracket-mounted installation.
• Low nighttime energy consumption.
• Integrated grid monitoring and electrical protection.

Integrated Safety and Protection Features

The SigenMicro 768 includes multiple protection features designed for modern grid-connected solar installations.

• Rapid shutdown: Supports rooftop solar rapid shutdown requirements.
• Anti-islanding: Monitors grid conditions and disconnects when required.
• Ground fault detection: Provides integrated electrical fault monitoring.
• Grid monitoring: Continuously monitors AC grid conditions.
• Surge protection: Supports protection against electrical surges.
• Galvanic isolation: High-frequency transformer architecture.
• Outdoor-rated enclosure: NEMA Type 6 protection.

Designed for Residential Rooftop Solar

The SigenMicro 768 is ideal for installers and homeowners building grid-connected solar arrays with modern high-output PV modules.

Common Applications

• Residential rooftop solar systems
• New grid-tied solar installations
• Solar arrays using two modules per microinverter
• Projects requiring individual panel optimization
• Solar systems with module-level monitoring
• Solar installations with multiple roof orientations
• Compatible solar array expansion projects
• Installations using Sigenergy monitoring and energy management

Product Specifications

Installation and System Integration

The SigenMicro 768 is designed for streamlined installation as part of a compatible grid-connected solar array.

• Connect up to two compatible solar panels to the microinverter's independent DC inputs.
• Mount the inverter using the approved bracket and installation hardware.
• Connect the AC output using compatible Sigenergy AC connection equipment.
• Configure WLAN Mesh communication and system monitoring.
• Commission the inverter through the supported Sigenergy setup process.
• Complete required electrical connections and grid interconnection procedures.

AC Connection: The plug-and-play connector is part of the microinverter's AC wiring system. The SigenMicro 768 US is a 240V grid-tied inverter, not a standard 120V household plug-in inverter.
