Samlex DC-DC Converter DC-DC IDC-200A-24 | 9–18VDC Input, 24VDC Output Fully Isolated
MPN No: IDC-200A-24
Expected ship date Feb 01 - 08
In Stock
$181.34
Samlex DC-DC Converter DC-DC IDC-200A-24 | 9–18VDC Input, 24VDC Output Fully Isolated
Samlex DC-DC Converter DC-DC IDC-200A-24 | 9–18VDC Input, 24VDC Output Fully Isolated
Regular price
$181.34
New
LESS THAN 50
Samlex DC-DC Converter DC-DC IDC-200A-24 | 9–18VDC Input, 24VDC Output Fully Isolated
Samlex DC-DC Converter DC-DC IDC-200A-24 | 9–18VDC Input, 24VDC Output Fully Isolated
Available
MPN No: IDC-200A-24
Regular price
$181.34
Expected ship date Feb 01 - 08
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Data Sheet
Regular price
$181.34
Samlex DC-DC Converter DC-DC IDC-200A-24 | 9–18VDC Input, 24VDC Output Fully Isolated
MPN No:
IDC-200A-24
Expected ship date Feb 01 - 08
Samlex Converter DC-DC Converter | 9–18VDC Input, 24VDC Output Fully Isolated
IDC-200A-24
The Samlex IDC-200A-24 is a rugged, fully isolated DC-DC step-up converter designed to reliably convert 12V DC systems (9–18V input) to a stable 24.5V DC output. Built for harsh mobile and industrial environments, it provides current-limited, short-circuit-protected power for sensitive 24V equipment operating from 12V vehicle or battery systems.
Key Technology
-
12V to 24V DC Step-Up Conversion
Converts 9–18V DC input to a regulated 24.5V DC output for 24V devices. -
Fully Isolated Design
Input-to-output isolation rated at >400V RMS protects connected equipment from electrical faults. -
Current-Limited & Short-Circuit Protected
Prevents damage during overload, wiring faults, or downstream shorts. -
Temperature-Controlled Cooling
Integrated fan adjusts automatically to maintain performance and reliability.
Best Uses
-
Heavy Trucks & Fleet Vehicles
Power 24V radios, controls, and accessories from 12V vehicle systems. -
Earth-Moving & Industrial Equipment
Supports mixed-voltage electrical architectures in demanding environments. -
Marine & Bus Applications
Reliable DC power conversion for onboard 24V electronics. -
12V / 24V Lighting & Audio Systems
Ideal for CB radios, AM/FM systems, and auxiliary lighting.
Protection & Reliability
-
Overload and short-circuit protection (output side)
-
Over-voltage protection (input and output)
-
Reverse polarity protection (input)
-
Over-temperature shutdown
Warranty & Compliance
-
Manufacturer Warranty: 2 years
-
EMC: EN50081-1 / EN61000-6-3 (Emissions), EN50082-1 / EN61000-6-1 (Immunity)
-
Automotive: 95 / 54 / EC
Product Specifications
| Specification | Details |
|---|---|
| Model | IDC-200A-24 |
| Converter Type | DC-DC Step-Up (Boost) |
| Input Voltage Range | 9 – 18 VDC |
| Output Voltage | 24.5 VDC |
| Output Current (Max) | 8 A |
| Peak Efficiency | 85% |
| Isolation | > 400 V RMS |
| Ripple & Noise | < 50 mV RMS |
| Cooling | Temperature-controlled fan |
| Operating Temperature | -20°C to +30°C (derates to 0 at 70°C) |
| Input Fuse (External) | 32V, 30A |
| Output Fuse (External) | 32V, 10A |
| Input Wire Size | AWG #6 (up to 6 ft) |
| Output Wire Size | AWG #12 (up to 10 ft) |
| Dimensions | 6.9 × 3.5 × 1.9 in |
| Weight | 1.4 lbs |
| Warranty | 2 years |
About Samlex:
Samlex is a global manufacturer of power conversion products founded in 1991 and based in Burnaby, Canada. They make inverters, battery chargers, converters, power supplies, solar charge controllers and related accessories for mobile, industrial, off‑grid, RV, marine and telecom uses. Samlex products are known for reliability, quality and broad international distribution.
Reliable 12V-to-24V Power for Demanding Mobile Systems
The Samlex IDC-200A-24 delivers safe, isolated, and dependable DC-DC voltage conversion—making it an ideal solution for vehicles and equipment that require stable 24V power from standard 12V electrical systems.
