S-5! Standing Seam Clamp (No-Bolt Version) S-5-Z Mini NB
The S-5-Z Mini NB is a light/medium-duty, non-penetrating clamp engineered for round “bulb” standing-seam profiles such as Zip-Rib®, BEMO, and Kalzip®. The NB (no-bolt) version ships without the top M8 flange bolt, letting installers choose bolt length/type per accessory. Its two-piece design installs anywhere along the rib and uses a single round-point setscrew to achieve high holding strength without piercing the panel.
Key Benefits
Purpose-Built for Bulb Seams: Designed specifically for round “bulb” seam geometries ≤ ~22–23 mm diameter (e.g., Zip-Rib®, BEMO, Kalzip®).
Non-Penetrating Grip: Round-point setscrew clamps to the seam without piercing panel coatings, preserving roof warranties.
Installer-Flexible NB Variant: Supplied without the M8 bolt so you can select the exact M8-1.25 hardware needed for your attachment.
Compact, Light-/Medium-Duty: “Mini” body with a single setscrew—ideal for utilities, PV attachments, and accessories that don’t require the full strength of a standard (two-setscrew) clamp.
Special Technology
M8-1.25 Top Thread: Built-in M8-1.25 threaded hole accepts S-5! PVKIT® studs, L-feet, or other accessories (bolt supplied separately with NB).
Two-Piece Body + Insert: Positions anywhere along the rib; insert and round-point setscrew develop high clamp forces on bulb seams.
Warranty
Manufacturer’s standard clamp warranty (S-5!).
Best Uses
Standing-Seam Metal Roofs (Bulb-Type): Mounting PV (with PVKIT® or rails), conduit, cable trays, small equipment, snow retention components, etc.
Specifications Table
| Specification | Data |
|---|---|
| Part Number | S-5-Z Mini NB |
| Clamp Type | Non-penetrating Mini clamp for bulb-shaped standing seams |
| Roof Seam Compatibility | Round “bulb” seams ≤ ~22–23 mm diameter (Zip-Rib®, BEMO, Kalzip®, etc.) |
| Top Attachment | M8-1.25 threaded hole (bolt not included in NB version) |
| Setscrew | Single round-point setscrew (Mini); Torx/round-point style per S-5! spec |
| Material | Aluminum clamp body with stainless steel hardware |
| Weight | 0.26 lb |
| Finish | Mill / anodized aluminum (varies by distributor) |
| Typical Applications | PV mounting (rail-based or rail-free with PVKIT®), utilities, accessories |
| Notes | NB = “No Bolt” (order M8-1.25 bolt separately if required) |
About S-5!:
S-5! is a leading manufacturer of metal roof attachment systems for solar and other rooftop applications. Founded in 1992, the company specializes in non-penetrating clamps and mounts engineered for durability, ease of installation, and long-term roof integrity.
