S-5! Mini Clamp S-5-ZH Mini
S-5! Mini Clamp S-5-ZH Mini
Available
MPN No: S-5-ZH Mini
Regular price
$7.50
Expected ship date Jan 16 - 23
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Data Sheet
Regular price
$7.50
S-5! Mini Clamp S-5-ZH Mini
MPN No:
S-5-ZH Mini
Expected ship date Jan 16 - 23
S-5! Mini Clamp S-5-ZH Mini
The S-5-ZH Mini is a hinged, non-penetrating standing seam clamp engineered for round “bulb” seam profiles (e.g., Zip-Rib®, Kalzip®, BEMO) up to ≤ 7/8″ (22 mm) seam diameter. Its hinge prevents pinning the roof panel to the clip/halter—preserving thermal movement—making it ideal for solar and other light/medium-duty attachments.
Key Benefits
Purpose-Built for Bulb Seams: Fits Zip-Rib®, Kalzip®, BEMO, and similar round “bulb” seams ≤ 22 mm.
Hinged Design: Easier installation and avoids clamping the panel to the halter—maintains thermal float.
Solar-Ready: Compatible with the S-5-PVKIT® for rail-less PV mounting.
Special Technology
Round-Point Setscrew: Single T-30 Torx® round-point 3/8-24 setscrew delivers strong hold without panel penetration.
Mini Form Factor: “Mini” clamps use one setscrew (no M8 bolt) for economical, lighter-duty attachments.
Warranty
Manufacturer’s Standard Warranty (S-5!).
Best Uses
Rail-less PV: Pair with S-5-PVKIT on compatible bulb-seam roofs.
Light/Medium Accessories: Conduit, cable tray, walkways, and other utility attachments on qualifying seams.
Specifications Table
| Specification | Data |
|---|---|
| Model | S-5-ZH Mini |
| Roof Seam Type | Round “bulb” standing seams (Zip-Rib®, Kalzip®, BEMO, similar) ≤ 7/8″ (22 mm) diameter |
| Design | Hinged, two-piece clamp (prevents pinning to clip/halter) |
| Material | 6000-series aluminum body; stainless steel hardware |
| Setscrew | (1) 3/8-24 round-point setscrew, T-30 Torx® drive |
| Included Fastener | No M8 bolt included (use accessory fastener as required) |
| Typical Applications | Solar (with S-5-PVKIT), light/medium utility attachments |
| Weight | 49 lb |
| Finish | Mill (aluminum); accessories vary |
| Notes | Always verify clamp-to-panel compatibility with S-5! resources and load tables |
