Runergy 540W (Pallet of 36) Mono PERC Bifacial Solar Panel HY-DH144P8-540
B35/-525mm+125mm QC4.10 plus
Tier 1 PV Manufacturer – BloombergNEF Certified
The Runergy HY-DH144P8-540 is a 540 W P-type, bifacial dual-glass module with a 1500 VDC system rating and rugged 2.0 mm + 2.0 mm glass construction. It delivers up to 21.1% module efficiency with strong low-light behavior and certified snow/wind loading (5400 Pa / 2400 Pa).
Key Benefits
High Efficiency: Up to 21.1% at 540 W STC, enabled by advanced cell and manufacturing processes. :
Durability: 2.0 mm AR front glass + 2.0 mm rear glass for enhanced weathering and PID resistance.
Certified Loads: 5400 Pa front / 2400 Pa back static loading; IEC Class A fire performance.
Extended Warranties: 12-year product + 30-year linear power warranty (0.45%/yr after first year).
Special Technology
Bifacial Gain: Bifaciality 70% ± 10% supports meaningful rear-side contribution on reflective surfaces.
Half-Cell, MBB Layout: 144 mono PERC (182 mm) half-cells for lower resistive losses and improved shade tolerance.
Warranty
12-Year Product Warranty · 30-Year Linear Power Warranty.
Best Uses
C&I and Large Residential: High-power, low-LCOE arrays on rooftops or ground-mounts where longevity and mechanical strength matter.
Specifications Table
| Specification | Data |
|---|---|
| Ordering / Variant Tag (as requested) | HY-DH144P8-540 B35/-525mm+125mm QC4.10 plus |
| Power @ STC | 540 W |
| Module Efficiency | 21.1% |
| Vmp / Imp | 41.64 V / 12.97 A |
| Voc / Isc | 49.60 V / 13.86 A |
| Max System Voltage | 1500 V DC (IEC/UL) |
| Mechanical Dimensions (L × W × H) | 89.69 × 44.65 × 1.38 in |
| Weight | 72.09 lb |
| Front / Back Cover | 2.0 mm semi-tempered AR glass / 2.0 mm semi-tempered glass |
| Cells / Type | 144 (6×24) · Mono PERC 182 mm (p-type) |
| Junction Box | IP68, 3 bypass diodes |
| Cables (standard) | 4 mm² (IEC) / 12 AWG (UL); +400/-200 mm or customized |
| Connector | RY01 or similar (family spec) |
| Bifaciality | 70% ± 10% |
| Design Load (Front / Back) | 5400 Pa / 2400 Pa |
| Operating Temp | -40 °C to +85 °C |
| NMOT / NOCT | 42 ± 2 °C (NMOT) / 45 ± 2 °C (NOCT) |
| Temp. Coefficients (Pmax / Voc / Isc) | -0.35%/°C · -0.27%/°C · +0.05%/°C |
| Fire Class | IEC Class A |
| Packing | 36 pcs/pallet; 620 pcs/40' HQ |
| Certifications | IEC61215 / IEC61730 / UL61730; IEC61701 / IEC62716 / IEC60068; ISO9001 / ISO14001 / ISO45001 |
About Runergy:
Runergy (founded 2013) is a leading vertically integrated solar tech firm specializing in high-efficiency PERC and N‑Type cells and modules. With global facilities spanning China, Thailand, and the U.S., and 63 GW cell capacity plus 23 GW planned module capacity, it ranked top‑3 worldwide for cell shipments from 2020–2022. Runergy is also building a 5 GW module plant in Alabama to serve the U.S. market.
Why Buy From US Solar Supplier?
As an American founded company out of Kentucky, US Solar Supplier is committed to providing top-quality solar products, backed by the world’s leading manufacturers. Our promise is to get you the fairest price from the best brands that offer warranties you can count on.
We update our inventory daily with solar components that feature the latest technology. With a reputation for excellence and a dedication to customer satisfaction, we ensure that every product we sell meets the highest standards in the industry.
Need Assistance?
We’re here to help! If you have any questions or need more information before making your purchase, don’t hesitate to call us at 1-800-230-7004. Our knowledgeable and friendly team is ready to assist you with product details, installation advice, or the purchasing process.
Why Buy From Us?
Trusted Supplier: We work with Tier 1 manufacturers who stand behind their products.
Expert Support: Our team is here to guide you every step of the way.
Manufacturer-Backed Warranties: Enjoy peace of mind with the 12-year product warranty and a 30-year linear power output warranty directly from the manufacturer.
Easy and Secure Checkout: Your information is protected with top-notch security for a smooth, worry-free transaction.
Join the many satisfied customers who have trusted us for their solar needs. Add to your cart now to secure your high-efficiency solar panels and take the next step towards sustainable energy!
FAQs
Q: What is the power output of the HY-DH144P8-540 panel?
The HY-DH144P8-540 panel produces 540 watts of power, making it a highly efficient choice for both residential and commercial installations.
Q: Are HY-DH144P8-540 panels suitable for areas with low sunlight?
Yes, these panels are engineered to perform efficiently even in low-light conditions, such as cloudy days, hazy weather, or during early morning and late afternoon hours.
Q: What kind of warranty does HYGON Solar offer for the HY-DH144P8-540 panel?
HYGON Solar provides a 12-year product warranty and a 30-year linear power output warranty, ensuring reliable long-term energy performance and peace of mind.
Q: Are these panels compatible with different mounting systems?
Yes, the HY-DH144P8-540 panels are compatible with a wide range of standard mounting systems, allowing for both roof-mounted and ground-mounted installations.
Q: How durable are HY-DH144P8-540 panels in harsh weather conditions?
These panels are built to withstand extreme weather such as strong winds, heavy snow, and high temperatures. They feature anti-reflective tempered glass and a corrosion-resistant aluminum alloy frame for enhanced strength and longevity.
Q: Can HY-DH144P8-540 panels help me save on energy costs?
Absolutely! Their high module efficiency of up to 21.1% allows you to generate more electricity per square foot, reducing your utility bills and accelerating your solar payback period.
Q: How many panels do I need for my home?
This depends on your energy usage and available roof space. For a home or business consuming around 10,000 kWh annually, you would need approximately 19 to 20 HY-DH144P8-540 panels. Consult with a certified installer for an accurate system design.
Q: How many panels are in each pallet?
Each pallet includes 36 HY-DH144P8-540 panels, providing a convenient and cost-efficient option for larger installations.
