This listing is for one Pylontech FH48074-FH1 battery module
Minimum Purchase for an Operating System: 2 Battery Modules
The Pylontech Force H1 FH48074-FH1 is a modular high-voltage lithium iron phosphate (LiFePO4) battery designed for residential energy storage applications. Part of Pylontech’s Force Series, the system offers a scalable, stackable design that lets you configure storage capacity to match the needs of your home or energy system.
Important: The FH48074-FH1 is an individual battery module and cannot operate as a standalone battery. A minimum of two battery modules is required for operation, creating a 7.10 kWh / 96V battery system. The Force H1 platform supports configurations from 2 to 7 modules, providing total storage capacities from 7.10 kWh to 24.86 kWh.
Key Features
- Minimum 2 modules required for operation
- Scalable 7.10–24.86 kWh system capacity
- High-voltage architecture: 96V to 336V depending on module count
- Lithium Iron Phosphate (LiFePO4) cell technology
- 95% depth of discharge (DoD)
- Modular, stackable design for flexible system sizing
- Plug-and-play Force Series architecture
- Indoor or outdoor installation capability
- IP55 protection class
- CANBUS / Modbus RTU communication
- More than 8,000 cycles listed in the manufacturer specifications
- 15+ year design life
- Suitable for residential energy storage, solar self-consumption and peak-shaving applications
Force H1 System Configuration
| Battery Modules | System Capacity | System Voltage | System Weight |
|---|---|---|---|
| 2 – Minimum | 7.10 kWh | 96V | 191 kg |
| 3 | 10.65 kWh | 144V | 271 kg |
| 4 | 14.21 kWh | 192V | 352 kg |
| 5 | 17.76 kWh | 240V | 432 kg |
| 6 | 21.31 kWh | 288V | 513 kg |
| 7 | 24.86 kWh | 336V | 593 kg |
The Force H1 specification sheet shows configurations beginning at two modules, confirming the 7.10 kWh / 96V configuration as the minimum system size.
Technical Specifications
| Specification | Rating |
| Model | FH48074-FH1 |
| Battery Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Module Capacity | 74Ah |
| Energy per Module | Approx. 3.55 kWh |
| Minimum System Capacity | 7.10 kWh – 2 modules |
| Maximum System Capacity | 24.86 kWh – 7 modules |
| System Voltage Range | 96–336V |
| Depth of Discharge | 95% |
| Recommended Charge/Discharge Current | 14.5A |
| Maximum Charge/Discharge Current | 37A |
| Peak Current | 42A @ 15 sec. |
| Communication | CANBUS / Modbus RTU |
| Protection Class | IP55 |
| Maximum Stacks per System | 6 |
| Operating Temperature | 32°F–122°F |
| Storage Temperature | -4°F–140°F |
| Humidity | 5%–95%, non-condensing |
| Maximum Altitude | <6,562 ft |
| Design Life | 15+ years at 77°F |
| Cycle Life | >8,000 cycles at 77°F |
Expandable High-Voltage Energy Storage
The Force H1 platform makes it possible to start with the minimum two-module 7.10 kWh configuration and expand the battery stack as additional storage is needed. Up to seven modules can be combined in a stack for 24.86 kWh of total battery capacity at 336V.
This modular approach makes the Force H1 well suited for residential solar-plus-storage systems where energy requirements may change over time.
Applications
The Pylontech Force H1 is designed for applications including:
- Residential battery energy storage systems
- Solar PV energy storage
- Increased solar self-consumption
- Peak shaving
- Load shifting
- Backup-energy systems when paired with compatible equipment
- Energy management and VPP applications
What You Need to Know Before Ordering
This listing is for one Pylontech FH48074-FH1 battery module.
Two FH48074-FH1 modules are required at minimum to create an operating Force H1 battery system. A single module should not be purchased with the expectation that it will function as a complete standalone battery system.
Additional Force H1 system components and compatible power electronics may also be required depending on the installation. Always verify inverter and system compatibility before ordering.
Certifications Listed by Manufacturer
The Force H1 specification sheet lists the following authentication/certification standards:
VDE-AR-E 2510-50, IEC 62619, IEC 63056, CE-RED, CE-LVD, EU RED, UL1973, UL9540A and UN38.3.
Why Choose the Pylontech Force H1?
The Force H1 combines LiFePO4 battery chemistry, high-voltage operation and modular scalability in a clean, stackable residential storage platform. With 95% DoD, more than 8,000 listed cycles and configurations ranging from 7.10 kWh to 24.86 kWh, it provides a flexible foundation for residential solar and energy-storage systems.
