Philadelphia Solar 550W Phenex PS-M144(HCBF)-550W Bifacial Solar Panel

Philadelphia Solar 550W Phenex PS-M144(HCBF)-550W Bifacial Solar Panel

Regular price $159.99
Regular price -% Sale price $159.99
50 IN STOCK
Leave a Review

Philadelphia Solar 550W Phenex PS-M144(HCBF)-550W Bifacial Solar Panel

Philadelphia Solar 550W Phenex PS-M144(HCBF)-550W Bifacial Solar Panel

Philadelphia Solar
MPN No: PS-M144(HCBF)-550W
In Stock
Regular price $159.99
Regular price -% Sale price $159.99

1
2
3
4
5
6

Delivery

Shipping disclaimer: US Solar Supplier works hard to offer the most competitive shipping rates possible. Shipping is auto calculated. If you have questions, let's work together directly! Please reach out to arrange case based logistics. Contact our team at sales@ussolarsupplier.com or by chat during business hours 9 am to 5 pm EST.

Expected ship date Jan 21 - 24 About shipping

Payment

We offer multiple secure payment options for your convenience

View full details
Regular price $159.99
Regular price -% Sale price $159.99

Specifications

.PDF
Datasheet
Cell Type
Mono PERC
Number of Cells
144
Frame and Backsheet
Black/Silver
.PDF
Datasheet

Philadelphia Solar 550W Phenex PS-M144(HCBF)-550W Half Cell 10BB Bifacial 144 Cells

31 Panels/Per Pallet

Inquire about quantities of less than one pallet.

Special Features

  • High Power Output: Delivers up to 555W with 21.5% efficiency.
  • Bifacial Technology: Offers up to 65% bifacial gain for additional energy generation.
  • Durability: Withstands front loads up to 5400 Pa and rear loads up to 2400 Pa.
  • Performance Warranty: 25-year linear power warranty with only 0.5% annual degradation.

Technology Overview

The PHE144 540-555W features 144 half-cut monocrystalline PERC cells with 10BB technology, reducing internal resistance and improving efficiency. The module also has excellent performance in low-light conditions and enhanced temperature coefficients.

Installation

Designed for commercial, industrial, and large-scale solar installations, this module supports easy installation with MC4 connectors and high durability in harsh environments.

Installation Tips

  • Ensure proper rear-side clearance for optimal bifacial performance.
  • Use standard mounting systems for secure placement.

Applications

  • Utility-scale solar farms
  • Commercial rooftop installations
  • Solar power plants

Product Specifications

Specification Details
Power  550W
Module Efficiency Up to 21.5%
Cell Type Mono PERC, 10BB Half-Cell
Dimensions 44.65 x 89.69 x 1.38 in
Weight 66 lbs
Open Circuit Voltage (Voc) 49.78V - 50.50V
Short Circuit Current (Isc) 13.59A - 13.73A
Maximum System Voltage 1500V DC
Front/Back Load 5400 Pa / 2400 Pa
Warranty 12 years product
