Victron Energy MultiPlus 24/2000/50-50 120V Inverter Charger (PMP242200102)
The Victron Energy MultiPlus 24/2000/50-50 is a 24V inverter/charger designed for mobile, off-grid, and backup power systems that require reliable 120V AC power and seamless charging from shore or generator sources. Combining a pure sine wave inverter with an advanced battery charger in a single enclosure, the MultiPlus simplifies system design while delivering dependable performance.
This model is commonly used in RVs, vans, boats, cabins, and off-grid homes where a 24V battery bank is paired with household-style AC loads.
Key Benefits
Integrated Inverter & Charger
Provides 2,000 VA (1600 W) of continuous AC output while also functioning as a high-performance 50A battery charger when shore power or generator power is available.
Seamless Power Transfer
Automatically switches between inverter and AC input power, keeping loads running without interruption when plugging in or disconnecting from shore power.
Pure Sine Wave Output
Delivers clean, stable 120V AC power suitable for sensitive electronics, appliances, and tools.
PowerAssist Technology
Prevents overload of limited shore or generator power by supplementing AC input with battery power when demand spikes.
Flexible System Integration
Compatible with Victron MPPT solar charge controllers, battery monitors, and system accessories for scalable off-grid and mobile power systems.
Electrical Specifications
| Specification | Value |
|---|---|
| Battery Voltage | 24 VDC |
| AC Output Voltage | 120 VAC |
| Inverter Rating | 2000 VA (1600 W continuous) |
| Charger Output | 50 A |
| AC Input | Shore or Generator |
| Transfer Switch | Integrated |
| Output Waveform | Pure Sine Wave |
Physical Specifications
| Specification | Value |
|---|---|
| Dimensions (H × W × D) | 14.4 × 10.2 × 5.7 in |
| Weight | 26.5 lbs |
Applications
-
RVs & camper vans (24V systems)
-
Marine power systems
-
Cabins & off-grid homes
-
Backup power for critical loads
The Victron MultiPlus 24/2000/50-50 is a compact, all-in-one inverter/charger solution delivering 2000VA of true sine wave AC power and a sophisticated 50A battery charger. Designed for reliable off-grid and mobile power systems, it features PowerAssist technology, remote configuration options, and seamless switching between shore, generator, and battery power.
Key Benefits
Dual Functionality: Combines a pure sine wave inverter with a powerful adaptive battery charger in one enclosure.
PowerAssist Feature: Supplements shore or generator power when peak loads temporarily exceed supply capacity.
High-Speed Transfer: Switchover between grid and inverter is under 20 ms—ideal for sensitive electronics.
Smart Charging: 4-stage adaptive charging ensures maximum battery lifespan and performance.
Remote Configuration: Easily monitored and programmed using VictronConnect, VE.Bus Smart Dongle, or MK3-USB interface.
Special Technology
PowerControl: Limits charging power based on available shore/generator capacity to prevent tripping breakers.
Parallel & Split-Phase Ready: Connect multiple units for higher output or 120/240V split-phase operation.
Programmable Relay: Configurable for alarms, genset start/stop, or load disconnects.
VE.Bus Communication: Allows integration into Victron GX systems and the VRM online portal.
Warranty
Backed by Victron Energy’s 5-year limited warranty.
Best Use
Off-Grid Systems: Efficiently convert 24V DC to 120V AC while managing charging needs from solar or AC sources.
RVs & Marine: Trusted by mobile system installers for dependable AC power and quiet operation.
Backup Power Systems: Seamless switching ensures power continuity during outages.
Specifications Table
| Specification | Data |
|---|---|
| Model | PMP242200102 (MultiPlus 24/2000/50-50) |
| Input Voltage Range (DC) | 19 – 33 VDC |
| Nominal Output Voltage | 120 VAC ± 2% |
| Frequency | 60 Hz ± 0.1% |
| Continuous Output Power at 25°C | 2000 VA / 1600 W |
| Output Power at 40°C | 1450 W |
| Peak Power | 4000 W |
| Charger AC Input Voltage | 95–140 VAC |
| Battery Charger Current | 50 A |
| Charge Voltage - Absorption | 28.8 VDC |
| Charge Voltage - Float | 27.6 VDC |
| Zero Load Power | 11 W |
| Efficiency | Up to 94% |
| Transfer Switch | 50 A |
| Programmable Relay | 1 × (AC: 120V/4A, DC: 4A up to 35VDC) |
| Communication | VE.Bus, VE.Direct (via accessories) |
| Cooling | Fan-assisted |
| Protection Rating | IP21 |
| Dimensions (H × W × D) | 20.5 × 10.0 × 5.0 in |
| Weight | 25 lbs |
| Certifications | UL 458, UL 1741, EN-IEC 60335-1/2-29 |
| Warranty | 5-Year Limited |
