Midnite Solar 80 Amp DIN Rail Breaker 80 VDC MNEPV80-80-1PNP
MPN No: MNEPV80-80-1PNP
Expected ship date Nov 26 - Dec 03
In Stock
$34.03
Midnite Solar 80 Amp DIN Rail Breaker 80 VDC MNEPV80-80-1PNP
Midnite Solar 80 Amp DIN Rail Breaker 80 VDC MNEPV80-80-1PNP
Regular price
$34.03
New
LESS THAN 50
Midnite Solar 80 Amp DIN Rail Breaker 80 VDC MNEPV80-80-1PNP
Midnite Solar 80 Amp DIN Rail Breaker 80 VDC MNEPV80-80-1PNP
In Stock
MPN No: MNEPV80-80-1PNP
Regular price
$34.03
Expected ship date Nov 26 - Dec 03
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Data Sheet
Regular price
$34.03
Midnite Solar 80 Amp DIN Rail Breaker 80 VDC MNEPV80-80-1PNP
MPN No:
MNEPV80-80-1PNP
Expected ship date Nov 26 - Dec 03
In Stock
Midnite Solar 80 Amp DIN Rail Breaker 80 VDC MNEPV80-80-1PNP
The MNEPV80-80-1PNP is a 1-pole, 80 Vdc, 80 A hydraulic-magnetic circuit breaker used in PV combiner/enclosure applications. It’s 100% rated (unaffected by ambient temperature), DIN/mini-rail dual-mount, and UL 489A listed with up to 10 kA interrupt capacity—ideal for dependable DC branch protection in residential and commercial solar BOS.
Key Benefits
True 100% Rating: Hydraulic-magnetic mechanism maintains trip accuracy across temperature—no derating hassles.
High Interrupt Rating: Up to 10 kA (UL 489A) fault interruption at 80 Vdc for robust safety.
Installer-Friendly: Dual DIN & mini-rail mounting, compact 26 mm/pole width, and Pozidriv #2 terminals.
Special Technology
Hydraulic-Magnetic Trip: Precise, repeatable protection with medium U2 time-delay curve (7–10× In instantaneous trip).
Ambient-Independent: 100% rating capability reduces nuisance trips vs. thermal breakers.
Warranty
Manufacturer’s standard breaker warranty.
Best Uses
PV Combiners & Enclosures: DC branch/feeder protection in off-grid, hybrid, and grid-tied systems.
Energy Storage BOS: Battery and DC distribution panels needing UL 489A DC protection.
Specifications Table
| Specification | Data |
|---|---|
| Model / Part | MNEPV80-80-1PNP |
| Type | Hydraulic-magnetic miniature DC circuit breaker |
| Poles | 1-pole (26 mm module width) |
| Rated Voltage | 80 Vdc |
| Rated Current | 80 A |
| Time-Delay Curve | U2 (medium delay); instantaneous trip 7–10× In |
| Interrupt Capacity (UL) | 10 kA @ 80 Vdc (UL 489A) |
| Standards / Approvals | UL 489A; IEC/EN 60947-2; CSA C22.2 No.5-16; CE |
| Mounting | Dual mount: DIN & mini-rail |
| Terminal Wire Size | 14–1/0 AWG (1–50 mm²) |
| Terminal Torque | 35 lbf·in (≈4 N·m), Pozidriv #2 |
| Operating Temp | −40 °C to +85 °C |
| Dielectric / Impulse | 1–2 kVac 1 min; 4 kV impulse |
| Shock / Vibration | 50 G shock; 10 G vibration (MIL-STD-202) |
| Pollution Degree | PD2 |
| Weight | 1 lb |
