Midnite Solar 15 Amp 15A DIN Rail Breaker 300 VDC 1 - Pole MNEPV15-300-1PP
The MNEPV15-300-1PP is a high-performance 15 amp, 300V DC photovoltaic circuit breaker used throughout combiner boxes, E-Panels, and DC power distribution systems. Built on hydraulic-magnetic technology, this breaker delivers precise, temperature-independent protection for modern solar and battery applications.
Key Technology
-
Hydraulic-Magnetic Trip Design
Unaffected by ambient temperature—maintains accurate trip performance in harsh environments. -
300VDC Rated, Polarized Design
Designed specifically for high-voltage DC solar circuits with proper polarity marking. -
100% Continuous Current Rating
Rated to carry full current continuously without derating. -
Fast Reset Capability
Can be switched back ON immediately after tripping. -
Ultra-Compact Form Factor
13 mm width allows high circuit density in combiner and distribution panels.
Best Uses
-
PV String Protection
Ideal for protecting individual solar strings in combiner boxes. -
Battery & DC Distribution Circuits
Reliable DC over-current protection in off-grid and hybrid systems. -
MidNite Solar E-Panels & Combiners
Factory-standard breaker used across MidNite Solar enclosures. -
Professional Solar Installations
NEC-friendly, inspection-ready DC protection solution.
Warranty
-
Manufacturer Warranty: Standard MidNite Solar product warranty
Product Specifications
| Specification | Details |
|---|---|
| Model / Part Number | MNEPV15-300-1PP |
| Breaker Type | Hydraulic-Magnetic DC Circuit Breaker |
| Rated Current | 15 A |
| Maximum Voltage | 300 VDC |
| Number of Poles | 1 Pole |
| Mounting | Panel / DIN mount |
| Trip Technology | Hydraulic-Magnetic |
| Ambient Temp Range | -40°C to +85°C |
| Certifications | UL 489A, IEC 60947-2, CE, CSA |
| Typical Applications | PV strings, DC distribution, battery circuits |
About MidNite Solar:
MidNite Solar is a U.S.-based manufacturer known for innovative, NEC-compliant power electronics and solar components. Their product line includes combiner boxes, charge controllers, breakers, and battery enclosures designed for off-grid, grid-tied, and hybrid energy systems.
Industry-Standard DC Protection for Solar Systems
The MidNite Solar MNEPV15-300-1PP circuit breaker provides precise, reliable DC protection in a compact, professional-grade design—making it a trusted choice for solar installers and system designers worldwide.
