Midnite Solar 10 Amp DIN Rail Breaker 150 VDC MNEPV10-150-1PNP
MPN No: MNEPV10-150-1PNP
Expected ship date Nov 26 - Dec 03
In Stock
$20.96
Midnite Solar 10 Amp DIN Rail Breaker 150 VDC MNEPV10-150-1PNP
Midnite Solar 10 Amp DIN Rail Breaker 150 VDC MNEPV10-150-1PNP
Regular price
$20.96
New
116 IN STOCK
Midnite Solar 10 Amp DIN Rail Breaker 150 VDC MNEPV10-150-1PNP
Midnite Solar 10 Amp DIN Rail Breaker 150 VDC MNEPV10-150-1PNP
In Stock
MPN No: MNEPV10-150-1PNP
Regular price
$20.96
Expected ship date Nov 26 - Dec 03
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Data Sheet
Regular price
$20.96
Midnite Solar 10 Amp DIN Rail Breaker 150 VDC MNEPV10-150-1PNP
MPN No:
MNEPV10-150-1PNP
Expected ship date Nov 26 - Dec 03
In Stock
Midnite Solar 10 Amp DIN Rail Breaker 150 VDC - (1 - Pole 13 mm) MNEPV10-150-1PNP
The MNEPV10-150-1PNP is a 10 A, 150 Vdc, single-pole, non-polarized (reverse-feedable) hydraulic-magnetic circuit breaker for PV combiners and DC protection. Its 13 mm slim DIN module, constant 100% rating independent of ambient temperature, and UL 489B listing make it a reliable, code-ready choice for residential and commercial ESS/PV builds.
Key Benefits
Temperature-Independent Trip: Hydraulic-magnetic design maintains 100% rating regardless of ambient temp.
High Interrupt Rating: 10 kA at 150 Vdc (1-pole) per UL 489B for robust fault clearing on DC strings. :
Compact DIN Form Factor: Ultra-slim 13 mm width per pole saves rail space in combiner/enclosures.
Non-Polarized & Reverse-Feedable: Simplifies wiring and string landing orientation.
Special Technology
Hydraulic-Magnetic Mechanism: Precise, repeatable tripping with immediate re-close capability after a trip.
Aux/Alarm Options (family): Factory-fitted auxiliary switch and/or trip alarm available on the platform.
Warranty
Manufacturer’s Standard Warranty (MidNite/CBI platform).
Best Uses
PV String/Combiner Protection: 150 Vdc strings in rooftop or ground-mount arrays.
Battery & DC BOS: General DC circuits in ESS, telecom, and alternative energy gear.
Specifications Table
| Specification | Data |
|---|---|
| Part Number | MNEPV10-150-1PNP |
| Function | DC Circuit Breaker, Single-Pole, Non-Polarized |
| Rated Current | 10 A |
| Rated Voltage | 150 Vdc per pole |
| Interrupt Rating | 10 kA @ 150 Vdc (UL 489B, 1-pole) |
| Trip Technology | Hydraulic-magnetic; 100% rated independent of ambient |
| Time-Delay Curve | Medium (family option “M”); other curves available |
| Mounting | DIN rail, 13 mm module width (per pole) |
| Wiring / Terminals | 18–6 AWG (2.5–16 mm²) box terminals; 30 lbf·in torque |
| Approvals | UL 489B; IEC 60947-2; CE/UKCA; AS/NZS 60947-2 |
| Reverse Feed | Yes (unpolarized / reverse-feedable) |
| Operating Temperature | −40 °C to +85 °C |
| Dielectric / Impulse | 1000–2000 Vac, 1 min / 4 kV impulse (platform) |
| Mechanical Endurance | 10,000 ops (platform) |
| Shipping dimensions | 4L x 3W x 0.5D |
| Weight | 0.2 lb |
| Typical Applications | PV combiners, ESS DC circuits, telecom DC, UPS |
