IronRidge UFO GM-BRC-002 Bonding Rail Connector

IronRidge UFO GM-BRC-002 Bonding Rail Connector

Regular price $14.40
Sale price $14.40 Regular price
LESS THAN 50
No reviews
Leave a Review

MPN No: GM-BRC-002

IronRidge UFO GM-BRC-002 Bonding Rail Connector

IronRidge UFO GM-BRC-002 Bonding Rail Connector

No reviews
Leave a Review
Regular price $14.40
Sale price $14.40 Regular price

1
2
3
4
5
6

View full details
Description
Questions
Reviews
Ironridge
Manufacturer
Ironridge
Weight
0.6 lb
Dimension
(LxWxH): 0.8 x 0.3 x 0.8 inches
IRONRIDGE UFO GM-BRC-002 Bonding Rail Connector

The bonded rail connector attaches and bonds horizontal cross pipes to the XR1000 Rails. Each rail requires two connectors to create a secure and bonded attachment. Available for both 2” and 3” sizes, these rail connectors are manufactured using extruded 6000 series aluminum. Review the images in the ground mount specifications and manual for added context.


Description image


Specifications

Model IRONRIDGE UFO GM-BRC-002
Series Bonded Rail Connector
Manufacturer Iron Ridge


GENERAL SPECIFICATION

Type  Grounding
Finish  Mill Finish
Material  Aluminum
Dimension
2 Inch


Warranty

  • 25 Years Product Warranty.

* Refer to warranty document for terms and conditions
Documentation

Data Sheet


Detailed Information

The Universal Fastening Object (UFO) family of components eliminates the need for separate grounding hardware by bonding solar modules directly to IronRidge XR Rails. All IronRidge system Installation types (Flush Mount, Tilt Mount and Ground Mount) that feature the UFO family of products are fully listed to the UL 2703 standard. UFO hardware forms secure electrical bonds with both the module and the rail, resulting in many parallel grounding paths throughout the system leading to safer and more reliable installations.

IronRidge's Bonded Rail Connectors attaches and bonds horizontal 2' Schedule 40 cross pipes to XR1000 Rails. Each rail requires two connectors to create a secure and bonded attachment. The Rail Connector is manufactured using extruded 6000 series aluminum and is also available in 3' size.

High reliability

Cell interconnections and diode placement use well-established industry practice and are field-proven to provide excellent reliability.

Each rail requires two connectors to create a secure and bonded attachment

All components were checked for structural stability

It's easy to develop, share, and price projects using online apps.
