Fortress Power Envy Duo 21 16kW Whole Home Solar Hybrid Inverter Envy Duo 21-US (16KW)
MPN No: Envy Duo 21-US (16KW)
Expected ship date Nov 26 - Dec 03
In Stock
5,398.00
-6%
$5,065.00
Sale
Fortress Power Envy Duo 21 16kW Whole Home Solar Hybrid Inverter Envy Duo 21-US (16KW)
Fortress Power Envy Duo 21 16kW Whole Home Solar Hybrid Inverter Envy Duo 21-US (16KW)
Regular price
$5,398.00
-6%
$5,065
6% OFF
LESS THAN 50
Sale
Fortress Power Envy Duo 21 16kW Whole Home Solar Hybrid Inverter Envy Duo 21-US (16KW)
Fortress Power Envy Duo 21 16kW Whole Home Solar Hybrid Inverter Envy Duo 21-US (16KW)
In Stock
MPN No: Envy Duo 21-US (16KW)
Regular price
$5,398.00
-6%
$5,065
Expected ship date Nov 26 - Dec 03
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Data Sheet
Regular price
$5,398.00
-6%
$5,065
Fortress Power Envy Duo 21 16kW Whole Home Solar Hybrid Inverter Envy Duo 21-US (16KW)
MPN No:
Envy Duo 21-US (16KW)
Expected ship date Nov 26 - Dec 03
In Stock
Sale
Fortress Power Envy Duo 21 16kW Whole Home Solar Hybrid Inverter Envy Duo 21-US (16kW)
Compatible products:
Fortress eFlex Max 5.4 kWh 51.2V Battery
Fortress Power 16kWh eBoost LFP Battery
Unmatched power and versatility for residential and commercial solar applications.
The Fortress Power Envy Duo 21 is a next-generation hybrid inverter engineered to handle whole-home energy needs with built-in reliability, scalability, and advanced safety features. Whether you’re on-grid, off-grid, or using a hybrid setup, this inverter delivers exceptional performance in all conditions.
Key Benefits
-
Massive Power Handling – Supports up to 16kW continuous on-grid output and 12kW continuous off-grid output.
-
High PV Input Capacity – Connect up to a 21kW solar PV array for maximum energy harvest.
-
Whole-Home Backup – Built-in 200A transfer switch seamlessly powers critical and non-critical loads during outages.
-
Flexible Voltage & Phases – Compatible with 120/240V single & split phase, 120/208V three phase, and 127/220V single & split phase at 50/60Hz.
-
Outdoor-Ready – Rugged IP65 weatherproof rating ensures safe installation indoors or outdoors.
-
Pre-Configured Safety – Comes with pre-built AC & DC breakers included for streamlined installation.
-
Built-in RSD Compliance – Equipped with an APsmart rapid shutdown transmitter for NEC 690.12 compliance.
-
Smart Design – Pre-integrated components reduce install time and simplify system wiring.
Special Technology
3× MPPT Architecture: Inputs per tracker (2:2:1) with wide 100–550 V DC range enable flexible stringing.
Fast Transfer: <20 ms switchover helps keep critical loads online during grid events.
Advanced Protection: AFCI, RSD, PV ground-fault monitoring, surge protection (DC Type III / AC Type II), anti-islanding.
Warranty
10-Year Manufacturer Warranty.
Best Uses
Whole-Home Backup & TOU Shifting: Seamless PV + battery operation with generator-ready capability.
Light Commercial / Microgrids: Parallel stacks up to 120 kW with flexible 208/240 V deployments.
Specifications Table
| Specification | Data |
|---|---|
| Model | Envy Duo 21-US (16 kW) |
| PV Max / Recommended Max | 25,000 W / 21,000 W |
| MPPTs / Inputs per MPPT | 3 / 2:2:1 |
| DC Voltage Range / MPPT Range | 100–550 Vdc / 120–440 Vdc |
| Start Voltage / MPPT Nominal | 100 Vdc / 360 Vdc |
| Max Usable Input Current (A) | 26 / 26 / 15 |
| Max Short-Circuit Current (A) | 31 / 31 / 19 |
| AC Grid Output | |
| Grid Voltages | 120/240 Vac split-phase; 120/208 Vac 3-phase |
| Max Output Power with PV | 16,000 W @ 240 V; 13,800 W @ 208 V |
| Continuous (Battery-Only) | 12,000 W @ 240 V / 208 V |
| Max Output Current (PV assist) | 66.7 A |
| Frequency / Range | 50/60 Hz / 55–65 Hz |
| Power Factor / THDi | 0.99 @ full load / <3% |
| Backup Output | |
| Nominal Output | 120/240 V or 120/208 V |
| Continuous Power / Peak | 12,000 VA / 2× Pn for 0.5 s |
| Switching Time | <20 ms |
| THDv | <3% |
| Efficiency | |
| PV→Grid / Battery→Grid | 97.5% / 94% |
| CEC Weighted | 96.9% |
| Battery | |
| Nominal / Range | 48 V / 40–60 V |
| Max Charge / Discharge Current | 250 A / 250 A |
| General | |
| Paralleling | Up to 10 units (120 kW total) |
| Enclosure | NEMA 4X / IP66 |
| Dimensions (W × H × D) | 22.3 × 35.2 × 11.2 in |
| Weight | 125.71 lb |
| Cooling | Smart cooling fans |
| Operating Temp | −25 °C to +60 °C (derate >40 °C) |
| Altitude / Humidity | < 6561 ft (2000 m) / 0–100% RH |
| Noise | < 67 dB |
| Idle Consumption | ~60 W |
| Display / Comms | Touch color screen / RS485, Wi-Fi, CAN |
| Safety & Certifications | AFCI, RSD, GFDI; UL1741 SA/SB, UL9540 (with Fortress batteries), IEEE 1547/1547.1, Rule 21, HECO 14H, FCC Part 15 Class B |
| Warranty | 10 Years |
