Enphase IQ System Controller 3 SC200D111C240US01
MPN No: SC200D111C240US01
Expected ship date Nov 26 - Dec 03
In Stock
$2,090.55
Regular price
$2,090.55
142 IN STOCK
Enphase IQ System Controller 3 SC200D111C240US01
Enphase IQ System Controller 3 SC200D111C240US01
In Stock
MPN No: SC200D111C240US01
Regular price
$2,090.55
Expected ship date Nov 26 - Dec 03
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Data Sheet
Regular price
$2,090.55
Enphase IQ System Controller 3 SC200D111C240US01
MPN No:
SC200D111C240US01
Expected ship date Nov 26 - Dec 03
In Stock
Enphase IQ System Controller 3 SC200D111C240US01
Introducing the Enphase SC200D111C240US01 IQ System Controller 3 – the central hub for managing your solar energy system. This advanced controller is designed to provide intelligent monitoring and control, optimizing the performance and efficiency of your solar setup.
- Advanced Monitoring: The IQ System Controller 3 by Enphase offers real-time insights into energy production, consumption, and system health, all accessible from your smartphone or computer.
- Efficient Energy Conversion: It maximizes energy conversion efficiency, ensuring that your solar system operates at its peak performance.
- Weather-Resistant: Built to withstand various weather conditions, guaranteeing long-term reliability and performance.
- Flexible Installation: Installing the IQ System Controller 3 is hassle-free, and it's compatible with Enphase microinverters and other Enphase products.
- 10-Year Warranty: Your investment is protected with a 10-year warranty for peace of mind.
Important Notes:
(1) Factory installed quad breaker (Siemens or Eaton). NFT pre-wired to 40 A terminal of the quad breaker.
(2) Two unit of CT-200-SPLIT or CT-200-CLAMP to be bought separately for generator integration
(3) The IQ System Controller 3 is rated at 22 kAIC.
(4) Integrated hold down kit also support breakers (BR220/BR230/BR240) without predrilled hole.
(5) "~" indicates alternating current (AC) supply.
also emphasize that this model Does not support generator integration. If it's needed we can offer USSE100-0437 SC200G111C240US01 - IQ System Controller 3G
Technology and Overview
The IQ System Controller 3 by Enphase incorporates state-of-the-art technology, allowing you to monitor and manage your solar system with precision. It offers real-time insights into energy production, consumption, and system health, all from the convenience of your smartphone or computer.
Installation and Compatibility Overview
Installing the IQ System Controller 3 is straightforward, making it a seamless addition to your existing solar energy system. It's compatible with Enphase microinverters and other Enphase products, ensuring a hassle-free integration process.
Benefits and Applications Overview
The Enphase IQ System Controller 3 provides a range of benefits, including:
- Efficient energy management for maximum savings
- Remote monitoring and control for convenience
- Enhanced system reliability and performance
- Compatibility with various solar panel brands
- Easy integration into smart energy management systems
Its versatile applications range from residential rooftops to large-scale solar farms. Whether you're looking to save money, reduce your carbon footprint, or power your business sustainably, the IQ System Controller 3 has you covered.
Product Specifications
| MODEL NUMBER | SC200D111C240US01 |
|
Description |
IQ System Controller 3 streamlines grid-independent capabilities of PV and storage installations. Integrates hold-down capability. Supports up to 40 kWH (without PCS*) and 80 kWh (with PCS*) IQ Battery 5P. Does not support generator integration |
| IQ System Controller 3/3G | Includes neutral-forming transformer (NFT) and microgrid interconnect device (MID) |
| System Shutdown Switch | Includes pre-wired red, black, orange and purple 12 AWG wire (EP200G-NA-02-RSD) |
| Wall-mounting bracket | Screws provided in the accessories kit for mounting |
| 4-pole circuit breaker | Pre installed Quad breaker (BRK-20A40A-4P-240V), 20 A-40 A, 10 kAIC, Eaton BQC2202402 |
| Accessories Kit | IQ System Controller 3/3G literature kit, including labels, CTRL headers, screws, filler plates, and QIG (EP200G-LITKIT) |
| CT-200-SPLIT | 200 A split core current transformers for metering (accuracy: ±2.5%)³ |
| CT-200-CLAMP | 200 A clamp-type current transformers for metering (accuracy: ±2.5%)³ |
|
Circuit breakers (order separately, as needed)4 : • BRK-100A-2P-240V : Main breaker, 2-pole, 100A, 25kAIC, CSR2100N or CSR2100 • BRK-125A-2P-240V: Main breaker, 2-pole, 125A, 25kAIC, CSR2125N • BRK-150A-2P-240V: Main breaker, 2-pole, 150A, 25kAIC, CSR2150N • BRK-175A-2P-240V: Main breaker, 2-pole, 175A, 25kAIC, CSR2175N • BRK-200A-2P-240V: Main breaker, 2-pole, 200A, 25kAIC, CSR2200N |
Circuit breakers (order separately, as needed)5 : • BRK-20A-2P-240V-B: Circuit breaker, 2-pole, 20 A, 10 kAIC, BR220B/BR220 • BRK-30A-2P-240V-B: Circuit breaker, 2-pole, 30 A, 10 kAIC, BR230 • BRK-40A-2P-240V-B: Circuit breaker, 2-pole, 40 A, 10 kAIC, BR240B/BR240 • BRK-60A-2P-240V: Circuit breaker, 2-pole, 60 A, 10 kAIC, BR260 • BRK-80A-2P-240V: Circuit breaker, 2-pole, 80 A, 10 kAIC, BR280 |
| EP200G-HNDL-R1 | IQ System Controller 3/3G installation handle kit (order separately) |
| CTRL-SC3-NA-01 | Control cable, 500 ft. spool (order separately) |
| Nominal voltage/Range (L-L) | 240 V~6/±20% |
| Voltage measurement accuracy | ±1% V nominal (±1.2V L-N and ±2.4V L-L) |
| Auxiliary (dry)contact for load control, excess PV control, and generator two-wire control | 24 V, 1 A |
| Nominal frequency/Range | 60 Hz/56–63 Hz |
| Frequency measurement accuracy | ±0.1 Hz |
| Maximum continuous current rating | 160 A |
| Maximum input overcurrent protection device | 200 A |
| Maximum output overcurrent protection device | 200 A |
| Maximum overcurrent protection device rating for generator circuit | 80 A (IQ System Controller 3G only - SC200G111C240US01) |
| Maximum overcurrent protection device rating for storage circuit | 2x 80 A (IQ System Controller 3 - SC200D111C240US01), 1x 80 A (IQ System Controller 3G -SC200G111C240US01 ) |
| Maximum overcurrent protection device rating for PV combiner unit | 80 A |
| Internal busbar rating | 200 A |
|
Neutral-forming transformer (NFT) • Breaker rating (pre-installed): 40A between L1 and Neutral; 40A between L2 and Neutral • Continuous rated power: 3,600 VA |
• Maximum continuous unbalance current: 30 A @ 120 V • Peak rated power: 8,800 VA for 30 seconds • Peak unbalanced current: 80 A @ 120 V for 2 seconds |
| Dimensions (WxHxD) | 50 cm x 91.6 cm x 24.6 cm (19.7 in x 36 in x 9.7 in) |
| Weight | 39.4 kg (87 lbs) |
| Ambient temperature range | -40°C to 50°C (-40°F to 122°F) |
| Cooling | Natural convection, plus heat shield |
| Enclosure environmental rating | Outdoor, NEMA type 3R, polycarbonate construction |
| Maximum altitude | 2,500 meters (8,200 feet) |
|
Connections (All lugs are rated to 90°C) |
Main lugs and backup load lugs - Cu/Al: 6 AWG–300 kcmil CSR breaker bottom wiring lugs - Cu/Al: 2 AWG–300 kcmil AC combiner lugs, IQ Battery lugs, and generator lugs - 14 AWG–2 AWG Neutral (large lugs) :- Cu/Al: 6 AWG–300 kcmil |
| Neutral and ground bars | Large holes (5/16–24 UNF) - 14 AWG–1/0 AWG Small holes (10–32 UNF) - 14 AWG–6 AWG |
| Compliance (under progress) | UL 1741, UL 1741 SA, IEEE 1547:2018 (UL 1741-SB, 3rd Ed.), UL 1741 PCS CRD, UL1 998, UL 869A, UL 675, UL 5087 , UL 50E7 CSA 22.2 No. 107.1, 47 CFR Part 15 Class B, ICES 003, ICC ES AC156. The IQ System Controller 3/3G is approved for use as service equipment in the United States |
| Limited warranty (restrictions apply) | Up to 10 years (EP200G-NA-02-RSD is warrantied for 5 years) |
| COMPATIBILITY | IQBATTERY-5P-1P-NA, IQ6, IQ7, IQ8, and M8 Series Microinverters9, X-IQ-AM1-240-5C, X-IQ-AM1-240-5, COMMS-KIT-02 |
