Eaton Type BR Breaker 20/2 Pole 120/240V BR220B
MPN No: BR220B
Expected ship date Jun 11 - 18
In Stock
$29.45
Regular price
$29.45
LESS THAN 50
Eaton Type BR Breaker 20/2 Pole 120/240V BR220B
Eaton Type BR Breaker 20/2 Pole 120/240V BR220B
Available
MPN No: BR220B
Regular price
$29.45
Expected ship date Jun 11 - 18
Ships from U.S. Warehouse
Trusted by Thousands
Expert U.S. Support
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Data Sheet
Regular price
$29.45
Eaton Type BR Breaker 20/2 Pole 120/240V BR220B
MPN No:
BR220B
Expected ship date Jun 11 - 18
Eaton Type BR Breaker 20/2 Pole 120/240V BR220B
The BR220B is a Type BR thermal magnetic circuit breaker designed for reliable overcurrent protection in residential and light commercial electrical systems. This two-pole, 1-inch plug-on breaker is UL-listed and engineered for use in Eaton Type BR loadcenters, offering dependable performance, compact form factor, and long service life.
Key Technology
-
Thermal Magnetic Protection
Combines thermal and magnetic trip mechanisms to protect against overloads and short circuits. -
Two-Pole, Common Trip Design
Ensures simultaneous disconnection of both poles for enhanced safety on 120/240V circuits. -
Type BR Plug-On Installation
One-inch plug-on design allows fast, secure installation in compatible Eaton BR loadcenters. -
10 kAIC Interrupt Rating
Rated to safely interrupt fault currents up to 10,000 A. -
Special Application – Tapped Molded Opening
Designed for specific installation requirements within BR panel systems.
Best Uses
-
Residential Loadcenters
Ideal for branch circuit protection in homes using Eaton Type BR panels. -
Light Commercial Electrical Systems
Suitable for small commercial installations requiring 2-pole 20A protection. -
120/240V Circuits
Commonly used for multi-wire branch circuits and dedicated loads.
Warranty
-
Residential Warranty: Limited lifetime
-
Commercial Warranty: 1 year
Product Specifications
| Specification | Details |
|---|---|
| Manufacturer | Eaton |
| Catalog Number | BR220B |
| Breaker Type | Type BR, Thermal Magnetic |
| Number of Poles | 2-Pole |
| Amperage Rating | 20 A |
| Voltage Rating | 120 / 240 VAC |
| Interrupt Rating | 10 kAIC |
| Trip Type | Common trip |
| Mounting Method | Plug-on |
| Wire Size | #14–4 AWG Cu / Al |
| Compatible Loadcenters | Eaton Type BR |
| Dimensions (L × W × H) | 3 × 2 × 3 in |
| Weight | 0.5 lb |
| Certifications | UL 489 |
About Eaton:
Eaton is a global power management company providing energy-efficient solutions for electrical, hydraulic, and mechanical systems. They help customers manage power safely, reliably, and sustainably across industries, buildings, and vehicles, delivering innovation that improves efficiency and reduces environmental impact.
Reliable Circuit Protection for Eaton BR Panels
The Eaton BR220B circuit breaker delivers trusted thermal-magnetic protection, compact plug-on installation, and UL-listed safety—making it a dependable choice for residential and light commercial electrical distribution systems.
