EG4 600A 12 Stud Bus Bar – Black EG4BUSBAR600ABL
NOTE: THIS IS A SINGLE BLACK BUS BAR
Shop the red version here.
The EG4 600A Bus Bar in black (Model EG4BUSBAR600ABL) is designed for high-current DC applications up to 600 amps. It includes 12 pre-threaded 5/16" terminals, allowing multiple battery cables, inverter wires, or fuses to connect to a centralized point. This bus bar is color-coded black for use as a negative terminal and features a durable aluminum base with a protective cover to maintain safety in battery or inverter enclosures.
Key Benefits
High Current Capacity: Handles up to 600 amps for large battery and inverter systems.
Multiple Connections: Features 12 × 5/16" stainless steel studs for secure cable terminations.
Insulated Base: Mounted on a rugged, insulated base to prevent accidental shorts.
Black Finish: Industry-standard color for negative bus applications.
Clear Cover Included: Protects from accidental contact and adds installation safety.
Special Technology
Conductive Aluminum Core: Optimized for high conductivity with minimal voltage drop.
Pre-Tapped Terminals: Precision-threaded 5/16" stainless studs ensure reliable torque.
Mounting Ready: Integrated base supports multiple mounting orientations.
UL Recognized Materials: Components meet quality and safety standards for energy storage.
Modular Matching: Designed to pair with EG4 red bus bar for dual polarity installs.
Warranty
The EG4 600A Bus Bar is backed by a 5-year limited warranty from EG4, ensuring reliable performance and build quality.
Best Use
Battery Banks: Centralizes all negative cable connections for clean battery layouts.
Inverter Systems: Ideal for use with 48V inverters and high-current distribution panels.
Solar Combiner Boxes: Simplifies cable management in solar-plus-storage systems.
RV & Off-Grid Power: Suitable for mobile power setups requiring heavy DC loads.
Specifications Table
| Specification | Data |
|---|---|
| Model Number | EG4BUSBAR600ABL |
| Rated Current | 600 Amps DC |
| Color Code | Black (Negative Bus) |
| Number of Terminals | 12 × 5/16" bolts |
| Material | Conductive aluminum bar, insulated base |
| Protective Cover | Included (clear acrylic) |
| Mounting Holes | Yes (pre-drilled base) |
| Dimensions (L × W × H) | 10.0 × 2.0 × 2.5 in |
| Weight | 1.8 lbs |
| Applications | Battery banks, solar, inverter, RV, marine |
| Warranty | 5-Year Limited Warranty |
About EG4 Electronics:
EG4 Electronics specializes in affordable, high-performance solar energy products including inverters, lithium batteries, and solar accessories. Known for user-friendly design and off-grid reliability, EG4 empowers residential and commercial energy independence.
