Bluetti Epanel Distribution Panel (For RV Solar RV5) RV5 Epanel
The BLUETTI RV5 Epanel is a compact, smart distribution panel that combines AC and DC power distribution with built-in monitoring and control. Designed for RVs, boats, and other compact power systems, it supports dual AC inputs, up to 8 AC circuits, and 20 DC circuits with smart overcurrent protection and app control via the BLUETTI app or Epad.
Key Benefits
All-in-One Power Hub: Integrates AC/DC distribution, labeling, and fuse/breaker management in a single enclosure.
Smart Circuits & Alerts: 4 smart AC + 6 smart DC circuits enable remote on/off and automatic protection with alerts for overcurrent/overvoltage.
Dual AC Inputs: MAIN1/MAIN2 support single or independent sources with a removable copper shorting bar.
Easy Commissioning: RJ45 communication (CAN/RS485 pins) for RV5/Epad; firmware updates via BLUETTI app.
Installer-Friendly: DIN-rail AC breakers, blade fuses for DC branches, bolt-on 150 A main DC fuse, and clear slot labels.
Special Technology
Smart Protection: Automatic shutdown on fault (AC: warn 30 A / protect 35 A; DC: warn 20 A / protect 25 A) with app notifications.
Fuse Status Indicators: Front indicators illuminate if a DC branch fuse is missing or blown when DC is on.
App/Panel Control: Real-time monitoring and remote control of smart circuits via BLUETTI app or Epad.
Warranty
Manufacturer Warranty (see BLUETTI documentation for regional terms).
Best Uses
RVs & Camper Vans: Centralized AC/DC distribution with remote control.
Marine & Off-Grid Cabins: Multi-circuit management with smart protections in compact installations.
Specifications Table
| Specification | Data |
|---|---|
| Model | RV5 Epanel (Smart Distribution Panel) |
| Application | RVs, boats, compact off-grid power systems |
| AC Side | |
| Rated AC Input Voltage / Frequency | 230 V · 50 Hz ± 3 Hz |
| Max Continuous Input Current | 50 A (main path) |
| AC Inputs / Breaker Type | Two inputs (MAIN1/MAIN2); DIN-rail 18 mm, 1-pole |
| AC Branch Circuits | 8 total (4 “smart” with internal switches & metering + 4 standard) |
| Max Output Current per AC Circuit | 30 A (branch breakers up to 32 A; main breaker up to 50 A) |
| DC Side | |
| DC Input Voltage Range / Max Current | 10–30 V · 100 A |
| Main DC Fuse | Bolt-on, 150 A (required) |
| DC Output Circuits | 20 total (6 smart + 14 standard) |
| Rated DC Output Voltage | 10–30 V |
| Max Output Current per DC Circuit | 20 A (blade fuses; indicators show blown/missing fuse) |
| Communications | |
| Ports | Dual RJ45 (CAN for RV5/Epad; reserved RS485 pins) |
| Termination | Selectable internal CAN termination (DIP switch) |
| Mechanical & Environmental | |
| Dimensions (W × H × D) | 17 × 13.89 × 4.12 in |
| Weight | 7.7 lb |
| Operating / Storage Temp | −20 to +45 °C / −20 to +70 °C |
| Max Operating Humidity | 90% RH |
| Ingress Protection | IP20 (indoor; add cover if exposed) |
| Clearance for Ventilation | ≥100 mm (≈4 in) around the unit |
| Installation Notes | |
| AC Wiring Range | 1.3–13 mm² to AC terminals; DIN-rail breakers |
| DC Wiring Range | Inputs: 2–20 AWG; Branch outputs: 10–30 AWG |
| Mounting | Wall-mount or recessed; includes drilling template & hardware |
