MidNite Solar 200A DIN Rail Breaker 80VDC 4-Pole MNEPV200-80-4PNP

The MNEPV200-80-4PNP is a high-capacity 200A DC circuit breaker with hydraulic-magnetic tripping and 80VDC rating, designed for demanding renewable energy applications. Featuring four poles and dual DIN/Mini rail mounting, this breaker offers 100% rating capability regardless of ambient temperature. With robust certifications including UL 489A and IEC 60947-2, it’s ideal for large PV, battery, telecom, or UPS installations.

Key Benefits

High Voltage Rating: Operates safely at up to 80 VDC for modern solar and battery setups.

200A Current Rating: Supports heavy DC loads like inverters, combiner boxes, or BESS units.

Hydraulic-Magnetic Technology: Maintains performance across wide temperature ranges.

Dual Rail Mounting: Fits DIN or mini-rail systems for universal enclosure integration.

Four-Pole Design: Supports bridging for split bus applications or multi-conductor DC disconnection.

Special Technology

Curve U2 Time Delay: Medium delay ideal for balancing startup surges with fault interruption.

10 kA Interrupt Capacity: High-level short-circuit withstand for system safety and resilience.

UL 489A & IEC Listed: Suitable for telecom, industrial, and alternative energy environments.

Ambient-Independent Tripping: Rated to perform from –40°C to +85°C without derating.

Warranty

Backed by MidNite Solar's 5-year limited hardware warranty for certified and residential-approved installations.

Best Use

Large PV Combiner Boxes: For high-current DC array protection in off-grid or commercial solar.

Battery Bank Disconnects: Safeguards 48V or parallel low-voltage battery systems.

Telecom & UPS Panels: Designed for mission-critical power distribution where reliability is key.

Industrial Power Rails: DIN-mountable in control panels or distribution boards.

Specifications Table

Specification Data
Model Number MNEPV200-80-4PNP
Rated Current 200 Amps
Rated Voltage 80 VDC
Poles 4 (2-pole bridged configuration)
Interrupting Capacity (UL) 10,000 A
Interrupting Capacity (IEC) 5,000 A
Mounting DIN Rail or Mini-Rail (Dual Mount)
Pole Width 26 mm per pole (Total: 104 mm)
Pole Spacing 52 mm between bridged poles
Trip Curve U2 (Medium Delay)
Temperature Range –40°C to +85°C (–40°F to +185°F)
Torque (Main Terminals) 35 in-lb (UL) / 4 Nm (IEC)
Terminal Wire Size 14 AWG to 1/0 AWG
Dielectric Strength 1000–2000 VAC (IEC) / 1000 VAC + 2×VDC (UL)
Impulse Withstand Voltage 4 kV
Weight Approx. 1.76 lbs
Approvals UL 489A, IEC/EN 60947-2, CE, AS/NZS 60947-2
Warranty 5-Year Limited Warranty



About MidNite Solar:

MidNite Solar is a U.S.-based manufacturer known for innovative, NEC-compliant power electronics and solar components. Their product line includes combiner boxes, charge controllers, breakers, and battery enclosures designed for off-grid, grid-tied, and hybrid energy systems.
