Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A Solar Charge Controller (SCC010030050)
MPN No: SCC010030050
Expected ship date Feb 19 - 26
In Stock
$58.65
Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A Solar Charge Controller (SCC010030050)
Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A Solar Charge Controller (SCC010030050)
Regular price
$58.65
98 IN STOCK
Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A Solar Charge Controller (SCC010030050)
Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A Solar Charge Controller (SCC010030050)
Available
MPN No: SCC010030050
Regular price
$58.65
Expected ship date Feb 19 - 26
We offer multiple secure payment options for your convenience
We offer multiple secure payment options for your convenience
Regular price
$58.65
Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A Solar Charge Controller (SCC010030050)
MPN No:
SCC010030050
Expected ship date Feb 19 - 26
Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A Solar Charge Controller (SCC010030050)
The Victron Energy BlueSolar PWM-LCD&USB 12/24V-30A is a reliable and cost-effective solar charge controller designed for smaller off-grid, RV, marine, and auxiliary solar systems. Using PWM (Pulse Width Modulation) technology, this controller safely regulates power from your PV array to your battery bank, preventing overcharge and extending battery life. The integrated LCD display and USB port make it easy to monitor system status and charge performance right at the controller.
Ideal for 12 V or 24 V systems up to 30 A, the BlueSolar PWM LCD&USB is a great match for small cabins, trucks, trailers, and compact solar projects where simplicity and reliability matter.
Key Benefits
Simple Charge Regulation
PWM technology delivers stable, efficient charging for lead-acid and lithium battery types, ensuring your batteries are protected without the complexity of MPPT.
Dual Voltage Compatible
Automatically recognizes and works with 12 V or 24 V battery systems — no switches or configuration needed.
Integrated LCD Display
On-board LCD shows real-time system data like battery voltage, charging current, and error indicators for quick diagnostics and monitoring.
USB Port for Monitoring/Power
Includes USB connectivity for device charging or auxiliary display power.
Easy Installation
Compact design and simple terminal layout make installation straightforward on RV battery boxes, marine panels, or off-grid solar racks.
Product Specifications
| Specification | Value |
|---|---|
| Model | BlueSolar PWM-LCD&USB 12/24V-30A |
| Part Number | SCC010030050 |
| Charge Technology | PWM (Pulse Width Modulation) |
| Nominal Battery Voltages | 12 V / 24 V (Auto Detect) |
| Max Charge Current | 30 A |
| USB Output | USB port (auxiliary) |
| Display | Integrated LCD |
| Battery Types Supported | Flooded, AGM, Gel, Lithium (set via display) |
| Protection | Reverse polarity, overcharge, short circuit |
| Mounting | Surface mount |
| Connections | Screw terminals |
| Environmental | Indoor / protected environment |
| Dimensions (H × W × D) | 3.1 × 6.7 × 1.7 in |
| Weight | ~0.8 lbs |
Note: PWM controllers don’t maximize energy harvest like MPPT controllers, but they are simple, rugged, and cost-effective for small solar setups where PV voltage closely matches battery voltage.
Applications
-
Small RV and camper solar systems
-
Marine solar charge regulation
-
Small off-grid cabins and sheds
-
Trailer and auxiliary battery charging
-
Side projects and auxiliary solar arrays
Why We Recommend It
The BlueSolar PWM-LCD&USB 12/24V-30A is a dependable choice for budget-conscious systems or smaller arrays where advanced MPPT features aren’t necessary. With easy setup, a clear display, and reliable charging protection, it’s ideal for DIY solar on RVs, boats, and tiny power installations.
