SMA Sunny Tripower X 30kW 480V Three-Phase Commercial Solar Inverter

High-Efficiency Grid-Tied String Inverter with 3 MPPTs, SMA ShadeFix and Integrated System Manager

30kW AC Output | Up to 45kW DC PV Array | 480V Three-Phase | 3 MPPT Trackers | 98% CEC Efficiency
The SMA Sunny Tripower X 30-US-50 is a powerful commercial solar string inverter designed for high-performance, grid-connected photovoltaic installations. Combining three independent MPPT trackers, SMA ShadeFix string optimization, integrated rapid shutdown signaling and advanced energy management, this 30kW inverter delivers flexible solar array design and intelligent system control.

Engineered for commercial rooftops, industrial facilities and other three-phase solar applications, the Sunny Tripower X 30kW supports up to 45,000W of connected PV array power and features an integrated System Manager capable of monitoring and controlling up to five compatible inverters.

With built-in Ethernet and Wi-Fi connectivity, SMA Smart Connected monitoring, and a durable Type 4X enclosure, the Sunny Tripower X is designed to simplify commercial solar installation, monitoring and long-term operation.

Product Highlights

• 30kW three-phase AC output: Designed for commercial 277/480V grid-connected solar installations.
• 45kW maximum PV array power: Supports flexible DC array sizing.
• Three independent MPPT trackers: Optimize production across different solar array sections.
• Six DC string inputs: Two string inputs per MPPT tracker.
• SMA ShadeFix: Integrated string-level optimization helps reduce shading-related energy losses.
• 98% CEC efficiency: Efficient DC-to-AC power conversion.
• Integrated System Manager: Monitors and controls up to five compatible inverters and one energy meter.
• 150kVA management capacity: Supports coordinated commercial PV system operation.
• SunSpec PLC rapid shutdown signal: Integrated communication for compatible module-level shutdown equipment.
• DC arc-fault protection: Advanced DC AFCI functionality.
• SMA Smart Connected: Proactive inverter monitoring and service support.
• Sunny Portal powered by ennexOS: Remote system visibility and management.
• Ethernet and Wi-Fi: Flexible network connectivity.
• Type 4X enclosure: Designed for demanding indoor and outdoor environments.
• 10-year standard warranty: Optional warranty extensions available.

30kW Commercial Solar Power with 480V Three-Phase Output

The SMA Sunny Tripower X 30-US-50 converts electricity generated by photovoltaic panels into grid-synchronized three-phase AC power for compatible commercial electrical systems.

With 30,000W of nominal AC output and a maximum apparent power rating of 30,000VA, this inverter is designed for commercial solar projects requiring reliable energy conversion and advanced grid-management capabilities.

AC Performance

• 30,000W nominal AC output power.
• 30,000VA maximum apparent power.
• 277/480V nominal three-phase AC connection.
• 36A maximum output current.
• 60Hz nominal grid frequency.
• 98% CEC efficiency.
• Less than 3% total harmonic distortion.

Three Independent MPPT Trackers for Flexible Solar Array Design

The Sunny Tripower X 30kW features three independent maximum power point trackers, each with two DC string inputs.

This configuration allows installers to design arrays across different roof sections and orientations while maintaining independent MPPT operation.

DC Input Specifications

• Maximum PV array power: 45,000Wp.
• Maximum DC input voltage: 1,000V.
• MPPT voltage range: 515–800V.
• Minimum input voltage: 150V.
• Initial input voltage: 188V.
• Independent MPPT trackers: 3.
• String inputs per tracker: 2.
• Maximum operating current per MPPT: 24A.
• Maximum short-circuit current per MPPT: 37.5A.

Final PV string sizing must account for module electrical characteristics, temperature-adjusted voltage, input current limits and the inverter's operating requirements.

SMA ShadeFix String-Level Optimization

SMA ShadeFix is an integrated optimization technology designed to help improve energy production when portions of a solar array experience shading.

Unlike systems that require an optimizer on every solar panel, SMA ShadeFix operates at the inverter's string level.

Benefits of SMA ShadeFix

• Helps reduce energy losses caused by partial shading.
• Supports efficient operation across multiple PV strings.
• Works with the inverter's three independent MPPT trackers.
• Reduces the need for additional module-level optimization hardware in suitable designs.
• Supports flexible commercial rooftop array layouts.

Actual energy gains depend on shading conditions, array configuration and system design.

Integrated System Manager for Commercial Solar Control

The Sunny Tripower X includes SMA's integrated System Manager, providing centralized monitoring, commissioning and control capabilities for compatible commercial solar installations.

Instead of requiring a separate external management device for every installation, the integrated System Manager can coordinate multiple supported inverters through SMA's ennexOS platform.

System Manager Capabilities

• Monitor and control up to five compatible inverters.
• Support up to 150kVA of total nominal inverter power.
• Integrate one supported energy meter.
• Centralize commissioning of connected devices.
• Access compatible devices remotely through Sunny Portal powered by ennexOS.
• Support optional SMA Dynamic Power Control functionality.

SMA Dynamic Power Control supports functions such as zero export and Volt-VAr control when appropriately configured. Availability and system requirements should be confirmed for the installation.

Integrated Rapid Shutdown and Arc-Fault Protection

The Sunny Tripower X 30-US-50 incorporates several electrical safety features designed for commercial photovoltaic installations.

Integrated Safety Features

• SunSpec PLC signaling: Integrated communication for compatible module-level rapid shutdown devices.
• DC AFCI: Arc-fault circuit interruption functionality.
• DC disconnect: Integrated load-rated DC disconnect.
• Ground-fault monitoring: Integrated fault detection.
• Grid monitoring: Monitors grid operating conditions.
• Reverse-polarity protection: Integrated DC protection.
• AC short-circuit protection: Built-in protection functionality.
• Residual-current monitoring: All-pole sensitive monitoring unit.

Important: The integrated SunSpec PLC signal does not mean module-level rapid shutdown receivers are included. Compatible equipment must be selected as required by the installation design and applicable electrical codes.

Smart Monitoring with SMA ennexOS

The Sunny Tripower X integrates with SMA's ennexOS energy management ecosystem for monitoring, remote access and system control.

Monitoring and Communication Features

• Sunny Portal powered by ennexOS.
• SMA Smart Connected proactive monitoring and service support.
• Two Ethernet ports.
• Integrated Wi-Fi connectivity.
• SMA Modbus communication.
• SunSpec Modbus communication.
• Speedwire communication.
• LED indicators for status, faults and communication.
• Six digital inputs.
• Multifunction relay and extension module slot.

Built for Demanding Commercial Installations

The Sunny Tripower X features a transformerless inverter design with SMA OptiCool active cooling technology.

Its variable-speed fan system helps manage operating temperatures, while the Type 4X enclosure supports installation in demanding environmental conditions.

Environmental and Mechanical Features

• Enclosure rating: Type 4X, according to UL 50E.
• Operating temperature: -13°F to +140°F (-25°C to +60°C).
• Cooling: OptiCool forced convection with variable-speed fans.
• Dimensions: 28.7 × 30 × 10.5 inches.
• Weight: 77 lbs.
• Typical noise emission: 59 dB(A).
• Relative humidity: Up to 100%, non-condensing.
• Mounting: Compatible wall or vertical rack installation.

Product Specifications

Compatible Accessories and Optional Equipment

The Sunny Tripower X supports additional SMA accessories for advanced system configuration and electrical protection.

• SMA Data Manager M: EDMM-US-10.
• DC Terminal Cover: DC-TERM-COVER.
• SMA Sensor Module: MD.SEN-US-40.
• Type 2 DC Surge Protection Kit: DC_SPD_KIT6-10.
• Type 1+2 DC Surge Protection Kit: DC_SPD_KIT7_T1T2.
• Compatible SunSpec rapid shutdown receivers: Selected according to system design.

Accessories and optional protection equipment are not included unless specifically identified in the selected product package.

Ideal Applications

• Commercial rooftop solar installations.
• Industrial photovoltaic systems.
• Warehouses and distribution centers.
• Agricultural and commercial facilities.
• Three-phase 480V solar installations.
• Commercial ground-mounted PV arrays.
• Multi-inverter commercial solar systems.
• Projects requiring integrated energy management.
• Solar arrays with multiple orientations or shading considerations.

10-Year Standard Manufacturer Warranty

The SMA Sunny Tripower X 30kW includes a 10-year standard manufacturer warranty.

Optional five-year and ten-year extensions are available, with total warranty coverage limited to 20 years under the manufacturer's published specifications.
