Solis 10kW 4G Single-Phase Inverter Solis-1P10K-4G-US-APST-RGM-PLUS
Solis 10kW 4G Single-Phase Inverter Solis-1P10K-4G-US-APST-RGM-PLUS
Solis 10kW 4G Single-Phase Inverter Solis-1P10K-4G-US-APST-RGM-PLUS
Solis 10kW 4G Single-Phase Inverter Solis-1P10K-4G-US-APST-RGM-PLUS
We offer multiple secure payment options for your convenience
Solis 10kW 4G Single-Phase Inverter Solis-1P10K-4G-US-APST-RGM-PLUS
Solis-1P10K-4G-US-APST-RGM-PLUS
Solis 10kW 4G Single-Phase Inverter Solis-1P10K-4G-US-APST-RGM-PLUS
The Solis-1P10K-4G delivers high-efficiency single-phase power conversion for residential and small commercial PV. With three independent MPPTs, wide 100–500 V operating range, low 120 V start-up voltage, and IP65 protection in a compact 18 kg package, it provides flexible string design and dependable grid compliance with natural-convection cooling.
Key Benefits
High Efficiency: Up to 98.1% max efficiency with 97.6% EU efficiency.
Flexible Stringing: 3 MPPTs (3 inputs) with 100–500 V MPPT range and 600 V max DC.
Low Start Voltage: 120 V start-up enables earlier energy harvest and shaded designs.
Installer-Friendly: MC4 DC connectors, quick AC plug, LCD interface; compact and lightweight.
Outdoor-Rated: IP65 aluminum enclosure and natural convection—no fans to service.
Special Technology
Precise MPPT Algorithm: Three trackers with fast, accurate tracking under changing irradiance.
High-Frequency Switching: Modern power stage for low THDi (<1.5%) and >0.99 power factor.
Integrated Protections: Reverse polarity, short-circuit, over-current, temperature, anti-islanding, surge protection; optional integrated DC switch.
Warranty
Manufacturer’s Standard Warranty (Solis).
Best Uses
Residential Rooftops: Multi-roof orientations with three MPPTs.
Small Commercial: Single-phase sites needing high efficiency and wide DC range.
Specifications Table
| Specification | Data |
|---|---|
| Model | Solis-1P10K-4G-US-APST-RGM-PLUS |
| Recommended Max PV Power | 11.5 kW |
| Max DC Voltage / Rated DC Voltage | 600 Vdc / 330 Vdc |
| Start-up Voltage | 120 Vdc |
| MPPT Operating Range | 100 – 500 Vdc |
| Number of MPPTs / Strings | 3 / 3 |
| Max Input Current (per MPPT) | 10 A / 10 A / 10 A |
| Max Short-Circuit Current (per MPPT) | 15.6 A / 15.6 A / 15.6 A |
| Rated AC Output Power | 10 kW |
| Max Apparent Output Power | 10 kVA |
| Rated Grid Voltage / Frequency | 1/N/PE, 220/230 Vac · 50/60 Hz |
| Rated Grid Output Current | 45.5 A / 43.5 A |
| Max Output Current | 45.9 A |
| Power Factor / THDi | >0.99 (0.8 lead–0.8 lag) / <1.5% |
| Max Efficiency / EU Efficiency | 98.1% / 97.6% |
| Protection Functions | Reverse-polarity, short-circuit, over-current, surge, grid monitoring, anti-islanding, over-temp |
| Integrated DC Switch | Optional |
| Enclosure / Cooling | IP65 / Natural convection |
| Operating Temp Range | -25 to +60 °C |
| Max Operating Altitude | 4000 m (≈ 13,123 ft) |
| Self-Consumption (Night) | < 1 W |
| Dimensions (W × H × D) | 13.11 × 22.56 × 9.80 in |
| Weight | 39.7 lb |
| Topology | Transformerless |
| DC / AC Connections | MC4 / Quick connection plug |
| Display / Comms | LCD (2×20); RS485; optional Wi-Fi or GPRS |
| Safety / EMC | IEC 62109-1/-2, IEC 62116, EN 61000-6-1/-2/-3/-4 |
| Grid Standards (examples) | VDE-AR-N 4105, EN 50549-1/-2, G98/G99, NRS 097-1-2, etc. |
| Warranty | Manufacturer Standard Warranty |
