S-5! ColorGard 2.0 Internal Splice for Snow Retention Crossmembers ColorGard 2.0 Splice

The S-5! ColorGard 2.0 Splice is the internal connector used to join two ColorGard 2.0 crossmember sections into a continuous snow-retention assembly. Designed as part of the next-generation ColorGard 2.0 system, the splice simplifies installation while maintaining a continuous, uninterrupted snow-retention barrier across the roof.

The updated internal splice design allows the VersaClip 2.0 to be installed directly over splice locations, eliminating the need to field-cut crossmembers at every splice. With ColorGard 2.0, field cutting is generally only required at the end of the overall assembly, helping reduce installation time and material handling on the roof.

A built-in center dimple is engineered to maintain a gap between adjoining ColorGard crossmember sections. This gap allows for normal expansion and contraction of the crossmembers while keeping the snow-retention system connected across the splice.

Key Technology

• Internal Crossmember Splice
  Designed specifically to join two sections of S-5! ColorGard 2.0 crossmember into one continuous snow-retention run.

• No In-Field Cutting at Splices
  The internal splice allows VersaClip 2.0 components to be placed directly over splice locations, reducing the need to cut crossmembers during installation.

• Continuous Snow-Retention Protection
  Connects adjoining ColorGard sections to maintain continuous, unbroken protection along the snow-retention assembly.

• Expansion & Contraction Gap
  A center dimple creates the intended spacing between crossmember sections so they can expand and contract without compromising the connection.

• ColorGard 2.0 Compatibility
  Purpose-built for use with the redesigned ColorGard 2.0 snow retention system.

• VersaClip™ 2.0 Compatible
  The new internal configuration allows the VersaClip to install directly over the splice location.

• Faster Lay-and-Play Installation
  Part of the redesigned ColorGard 2.0 architecture that eliminates the need to preassemble major components before accessing the roof.

• Included with Crossmembers
  S-5! states that the ColorGard 2.0 Splice is included with ColorGard 2.0 crossmembers.

Best Uses

• ColorGard 2.0 Crossmember Extensions
  Ideal for joining multiple ColorGard 2.0 crossmember sections when longer snow-retention runs are required.

• Standing-Seam Metal Roof Snow Retention
  Suitable as part of engineered ColorGard 2.0 snow-retention systems installed on compatible standing-seam metal roofs.

• Exposed-Fastened Metal Roof Systems
  ColorGard 2.0 is engineered for compatible exposed-fastened roof profiles when used according to site-specific S-5! engineering.

• New Construction & Retrofit Projects
  The redesigned system supports both new installations and retrofit modifications without requiring extensive preassembly.

• Projects Requiring Reduced Field Cutting
  Particularly useful where minimizing rooftop cutting and simplifying crossmember assembly are priorities.

Product Specifications

Simple Internal Connection for ColorGard 2.0 Crossmembers

The S-5! ColorGard 2.0 Splice provides a straightforward internal connection between adjoining ColorGard crossmembers. With its center expansion dimple, compatibility with VersaClip 2.0, no-cut splice installation, and continuous snow-retention design, it is an integral component of the improved ColorGard 2.0 system.

Important: S-5! identifies the splice as included with ColorGard 2.0 crossmembers. Verify whether a separate replacement splice is required before ordering.
