Jinko 460W Tiger Neo N-Type Monofacial Dual-Glass Solar Panel - Pallet of 37

High-Efficiency N-Type Solar Panels With Durable Dual-Glass Construction

The Jinko Solar JKM460N-48HL4M-DV is a high-efficiency 460W monofacial solar panel from the Tiger Neo series. It combines N-type TOPCon cells, HOT 3.0 technology and dual-glass construction in a compact module designed for strong output and dependable long-term performance.

Each panel delivers 23.02% module efficiency with a -0.29%/°C temperature coefficient. A full pallet includes 37 panels for 17.02kW of total rated DC capacity.

What’s Included

• (37) Jinko Solar JKM460N-48HL4M-DV 460W Solar Panels
• 17.02kW Total Rated DC Capacity

Please note: This listing includes one full pallet of solar panels. Inverter, racking, rapid shutdown equipment, wiring and other balance-of-system components are sold separately unless specifically stated.

Why Choose the Jinko 460W Tiger Neo?

• 23.02% module efficiency: Produces 460W in a compact 69.37 x 44.65-inch footprint.
• N-type TOPCon technology: Supports strong efficiency, improved low-light performance and reduced LID and LeTID degradation.
• HOT 3.0 technology: Jinko Solar’s optimized cell structure and materials improve reliability and energy output.
• SMBB cell design: Super Multi Busbar technology improves current collection and reduces electrical resistance.
• Dual-glass construction: The cells are protected by 2.0 mm front glass and 2.0 mm heat-strengthened back glass.
• Strong mechanical-load ratings: Rated for maximum static test loads of 6000 Pa on the front and 4000 Pa on the rear.
• Anti-PID performance: Cell-production and material controls help minimize degradation caused by potential-induced degradation.
• Low long-term degradation: Backed by a 30-year linear power warranty with 87.4% retained output at year 30.

Product Specifications

Connector note: Jinko lists MC4 and MC4-EVO2 as options available upon request and subject to availability. Confirm the connector installed on the delivered modules before selecting mating connectors or extension cables.

Warranty

• Product Warranty: 15 years
• Linear Power Warranty: 30 years
• First-Year Degradation: 1%
• Annual Degradation: 0.40% in years 2 through 30
• Guaranteed Output at Year 30: 87.4%

Standards Listed on the Manufacturer Datasheet

• IEC 61215:2021
• IEC 61730:2023
• IEC 61701
• IEC 62716
• IEC 60068
• IEC 62804

Always confirm equipment eligibility and installation requirements with the local authority having jurisdiction, utility, incentive program and project designer before purchase.

Freight Shipping and Receiving

This product is sold as a full pallet of 37 panels and ships by freight. The panels alone weigh approximately 1,957 lb. Final shipping weight will be higher after the pallet and protective packaging are included.

Please inspect the pallet and visible panels before signing the delivery receipt. Note any visible damage or shortage on the carrier’s delivery receipt and photograph the shipment before unpacking.

About Jinko Solar

Jinko Solar is a global photovoltaic manufacturer known for high-efficiency solar modules and advanced N-type cell technology. The Tiger Neo series is designed to provide strong energy production, low degradation and reliable long-term performance.
