Growatt 10kW Hybrid Inverter XH | Tigo Single-Core (150A) RSS Transmitter MIN 10000TL-XH US
The Growatt 10kW Hybrid Inverter XH is a powerful, battery-ready string inverter engineered for residential solar + storage systems. Designed to integrate seamlessly with energy storage, backup power solutions, and advanced safety protocols, this inverter brings premium performance and flexibility to modern homes.
With whole-home backup capability, Tigo rapid shutdown support, and multiple energy management modes, the Growatt 10kW Hybrid Inverter XH delivers dependable power, easy installation, and smart system control — perfect for homeowners and installers seeking a robust hybrid solution.
Key Features
-
10,000W Hybrid Output
Reliable 10kW AC capacity for solar + storage systems supporting whole-home or partial backup. -
Battery-Ready Hybrid Architecture
Works with both DC-coupled and AC-coupled battery systems for maximum configuration flexibility. -
Backup Power & Dark Start Support
Enables backup power capabilities and dark start operation when paired with compatible battery banks. -
Tigo Single-Core (150A) Rapid Shutdown Transmitter Support
NEC 2017/2020 compliant rapid shutdown when combined with Tigo RSS transmitters. -
Advanced Energy Modes
Self-consumption optimization, zero export, time-of-use (TOU) shifting, and off-grid options. -
High Efficiency Performance
Transformerless design with high peak and CEC efficiencies to maximize energy harvest. -
Smart Communications
Built-in Wi-Fi/Ethernet monitoring and optional RS485 connectivity for flexible system communications. -
Durable Outdoor Design
NEMA 4X / IP65 rating with natural convection cooling for long-term reliability.
Ideal Applications
-
Residential solar + battery storage installations
-
Homes with backup power requirements
-
Systems requiring NEC rapid shutdown compliance
-
TOU optimization and zero export utility programs
-
New builds or retrofit solar + storage upgrades
Battery & System Compatibility
-
Compatible with Growatt high-voltage battery series
-
Works with popular battery brands via AC coupling
-
Supports scalable storage capacities from small backup to whole-home systems
-
Integrates with ATS or SYN backup interfaces for seamless switchover
Warranty
-
10-Year Manufacturer Warranty
-
Optional extended warranty available up to 15 or 20 years
Product Specifications
| Specification | Value |
|---|---|
| Model | Growatt 10kW Hybrid Inverter XH |
| Nominal AC Power | 10,000 W |
| Max AC Apparent Power | ~12,000 VA |
| Nominal AC Voltage | 208V / 240V |
| Max Output Current | ~42 A |
| Max Efficiency | ~98%+ |
| CEC Efficiency (240V) | High CEC efficiency |
| MPPTs / Strings per MPPT | 2 / 2 |
| Max DC Voltage | ~600 V |
| Operating DC Voltage Range | ~200–500 V |
| Battery Voltage Range | Model-dependent (HV support) |
| Cooling | Natural Convection |
| Enclosure Rating | NEMA 4X / IP65 |
| Operating Temp Range | Typically –13°F to 140°F (–25°C to 60°C) |
| Dimensions (W×H×D) | 15.8 × 25.2 × 7.4 in |
| Weight | ~40–50 lbs |
| Communications | Wi-Fi/Ethernet, RS485 |
| Rapid Shutdown | Tigo RSS / compatible transmitter support |
| Compliance | UL1741 SA/SB, IEEE1547, NEC 2017/2020 |
| Warranty | 10 Years (Extendable) |
Why Choose the Growatt 10kW Hybrid Inverter XH?
-
Installer-Friendly: Built-in rapid shutdown support, flexible battery coupling, and advanced energy modes streamline design and deployment.
-
Performance You Can Count On: High efficiencies mean better energy yield and optimized storage usage.
-
Future-Proof: Hybrid architecture with scalable battery support prepares your system for future expansion without costly upgrades.
