EG4 EG4MISPH24K Mini Split Hybrid AC/DC 2 Ton 24000 BTU Heat Pump
EG4MISPH24K
EG4 EG4MISPH24K Mini Split Hybrid AC/DC 2 Ton 24000 BTU Heat Pump
Key Features:
- 24,000 BTU Hybrid Mini-Split System – Provides efficient cooling and heating.
- Dual Power Inputs (AC/DC Hybrid) – Runs on solar panels (DC) and/or grid power (AC).
- 100% Daytime Solar Operation – Achieves full energy savings when powered directly by solar.
- Easy DIY Installation – Plug-n-cool quick-connect refrigerant line-set, no vacuum needed.
- Energy Star Certified Efficiency – SEER2 rating of 21 BTU/W for cost-effective operation.
- Heating & Cooling – Ideal for spaces up to 1,350 sqft with reliable performance.
- Wi-Fi Connectivity & Remote Control – Smart integration for real-time monitoring.
- IP65-Rated Outdoor Unit – Durable weather-resistant design.
- 5-Year Limited Warranty – Ensures long-term performance and reliability.
Best Applications:
- Off-grid homes, cabins, and tiny houses
- Grid-tied solar-powered HVAC systems
- Energy-efficient climate control for workshops, garages, and offices
- Remote and backup cooling/heating solutions
Advanced Technology & Performance:
The EG4 MISPH24K Hybrid Mini-Split allows direct solar panel connection with 90V – 380VDC input, enabling zero-cost daytime operation. With a highly efficient inverter compressor and multi-stage filtration, this system delivers superior cooling and heating while significantly reducing energy consumption.
Installation & Compatibility:
- Pre-charged with R410A refrigerant for a quick-connect setup.
- Supports PV input up to 380V VOC, eliminating the need for an additional inverter.
- Can run on AC grid power (208-240V) when solar input is unavailable.
About EG4 Electronics:
EG4 Electronics is a leader in energy-efficient and solar-powered solutions, specializing in solar inverters, lithium battery storage, and hybrid HVAC systems. Their innovative hybrid technology enables sustainable, low-cost energy solutions for residential and commercial applications.
Technical Specifications:
| Specification | 24K Hybrid Mini-Split (MISPH24K) |
|---|---|
| Power Input (AC/DC Hybrid) | 208-240VAC / 90-380VDC |
| Maximum Solar Input Voltage (VOC) | 380V |
| Maximum PV Amperage (ISC) | 12A |
| Rated Cooling Capacity | 24,000 BTU/h |
| Cooling Power Range | 6,100 – 25,200 BTU/h |
| Rated Heating Capacity | 26,000 BTU/h |
| Heating Power Range | 6,100 – 26,000 BTU/h |
| SEER2 Efficiency Rating | 21 BTU/W |
| HSPF2 Efficiency Rating | 9.6 |
| Refrigerant Type | R410A (Pre-Charged) |
| Pre-Charged Refrigerant Line Length | 16.4 ft (5m) |
| Maximum Pipe Length | 82 ft (25m) |
| Indoor Unit Dimensions (W x D x H) | 42.5” x 9.3” x 13.0” |
| Outdoor Unit Dimensions (W x D x H) | 35.4” x 13.3” x 27.6” |
| Indoor Sound Pressure (Turbo Mode) | 50 dB(A) |
| Outdoor Sound Pressure | 58 dB(A) |
| Operating Temperature (Cooling Mode) | 32°F – 131°F (0°C – 55°C) |
| Operating Temperature (Heating Mode) | 5°F – 86°F (-15°C – 30°C) |
| Warranty | 5-Year Limited Warranty |
