ECOSOLARIS 12,000 BTU Hybrid Solar Air Conditioner Heat Pump Mini Split – ECO-SPLIT-12K-R32-V2

What's Included

• Indoor Wall-Mounted Air Handler
• Outdoor Condensing Unit
• Remote Control
• 2m (6.5 ft) Drain Hose

Not included:

ECOSOLARIS Insulated Copper Line Set - 1/4'' and 3/8" - Standard 16FT SCA-LINESET-W-TWIN-1/4x3/8-16FT

ECOSOLARIS 14 gauge 4 Conductor Communication Cable for Mini Split - Standard 13FT ECO-ACC-IDU12K18K-COMMCBL-5M

Solar panels and mounting equipment are sold separately. You do not need a traditional solar inverter to connect solar panels directly to the mini split.

Harness the Power of the Sun for Cooling & Heating

The ECOSOLARIS 12,000 BTU Hybrid Solar Air Conditioner Heat Pump Mini Split is a revolutionary HVAC solution designed to dramatically reduce energy costs by running directly from solar panels. Unlike traditional mini splits that require a solar inverter, battery bank, or charge controller, the ECOSOLARIS system connects directly to solar panels using standard MC4 connectors, prioritizing free solar energy whenever sunlight is available.

Perfect for homes, cabins, workshops, tiny homes, off-grid properties, and energy-conscious homeowners, this innovative heat pump delivers year-round comfort while minimizing reliance on utility power. The system automatically supplements solar production with grid power when needed, ensuring uninterrupted operation day and night.

Why Choose the ECOSOLARIS Solar Mini Split?

Traditional solar-powered HVAC systems often require expensive inverters, batteries, and additional electronics. ECOSOLARIS takes a different approach.

The system operates primarily on direct current (DC) solar power from photovoltaic panels and seamlessly transitions to AC grid power when solar production decreases. This unique hybrid architecture reduces equipment costs, simplifies installation, and maximizes energy savings.

Key Benefits

✔ Direct solar panel connection using standard MC4 connectors

✔ No solar inverter required

✔ No charge controller required

✔ Optional battery compatibility for full off-grid operation

✔ Automatic solar-first operation

✔ Energy Star Certified

✔ High-efficiency heat pump technology

✔ Built-in WiFi monitoring and control

✔ Heating and cooling from a single system

✔ Operates in temperatures from 5°F to 131°F (-15°C to 55°C)

Four Flexible Operating Modes

One of the most attractive features of the ECOSOLARIS Hybrid Solar Mini Split is its ability to operate in multiple configurations depending on your energy goals.

1. Solar-Only Mode

Run entirely from solar panels during daylight hours with no grid connection required. Ideal for remote applications and daytime cooling.

2. Hybrid Solar + Grid Mode

The system prioritizes solar energy and automatically supplements with utility power when solar production is insufficient, providing maximum savings without sacrificing comfort.

3. Battery-Powered Off-Grid Mode

Pair the system with a 48V battery bank and DC-DC booster to achieve complete off-grid operation and backup capability during outages.

4. Grid-Only Mode

Install and operate like a conventional mini split today, then add solar panels later when you're ready.

Designed for Solar-Powered Living

Whether you're building an off-grid cabin, lowering utility bills, or increasing your home's energy independence, the ECOSOLARIS 12K is engineered specifically for solar applications.

Recommended solar input ranges from 900W to 1,400W, with higher wattage recommended for off-grid installations and lower wattage suitable for hybrid operation.

Ideal applications include:

• Bedrooms
• Home offices
• Small homes
• Cabins
• Tiny homes
• Workshops
• RV properties
• Remote buildings
• Energy-efficient additions

Recommended coverage area: 500–900 square feet depending on insulation, climate, ceiling height, and building construction.

High-Efficiency Heating and Cooling

The ECOSOLARIS 12K delivers powerful performance while consuming remarkably little electricity.

Cooling Performance

• Cooling Capacity: 12,000 BTU (3,500W)
• SEER2 Rating: 23.40
• EER: 13.74
• Cooling Power Consumption: 180–860W

Heating Performance

• Heating Capacity: 12,000 BTU (3,500W)
• HSPF2 Rating: 9.70
• COP: 3.90
• Heating Power Consumption: 180–905W

The result is year-round comfort with significantly lower operating costs than traditional electric heating and cooling systems.

Smart Controls Included

Manage your comfort from anywhere.

The ECOSOLARIS Solar Mini Split includes:

• Wireless Remote Control
• Integrated WiFi Connectivity
• iOS & Android App Control
• Temperature Scheduling
• Performance Monitoring

Technical Specifications

Who Is This System For?

The ECOSOLARIS 12K Hybrid Solar Mini Split is an excellent choice for:

• Homeowners looking to reduce utility bills
• Off-grid cabin owners
• Tiny home builders
• Solar enthusiasts maximizing self-consumption
• Rural properties with unreliable power
• Backup power and resilience applications
• Energy-conscious homeowners seeking solar-powered comfort

Why Buy the ECOSOLARIS 12K Hybrid Solar Mini Split?

Most mini splits consume electricity. The ECOSOLARIS 12K is designed to generate savings by directly utilizing solar power whenever the sun is shining. With no inverter, no charge controller, and no complicated solar equipment required, it offers one of the simplest ways to use solar energy for everyday comfort. Whether you're reducing electric bills, increasing energy independence, or building an off-grid retreat, the ECOSOLARIS Hybrid Solar Mini Split delivers efficient cooling and heating powered by the sun.
