SMA Pluggable Multi-Pole Surge Protector DC_SPD_KIT7_T1T2
The SMA DC SPD Kit 7 T1/T2 is a high-performance pluggable surge protection device designed for installation in sub-distribution boards. It provides both Class I and Class II protection (Type 1 and Type 2) with integrated thermal disconnection and visual fault indication, ensuring safety for PV and AC systems.
Key Benefits
Dual-Class Protection: Meets both Class I (Type 1) and Class II (Type 2) SPD requirements for comprehensive system protection.
High Surge Capability: Handles up to 50 kA discharge current (8/20 μs) and 12.5 kA impulse current (10/350 μs).
Visual Fault Indicator: Green/Not-Green flag system for easy monitoring of operational state.
Modular Design: Pluggable housing simplifies installation and maintenance.
Special Technology
Protective Elements: Equipped with high-energy Metal Oxide Varistors (MOVs) and Gas Discharge Tubes (GDTs).
Thermal Disconnection: Provides additional protection through internal thermal cutoff.
DIN Rail Mount: Installs on standard 35 mm DIN rails (EN 60715).
Warranty
Backed by SMA’s quality assurance and limited product warranty.
Best Uses
PV Installations: Ideal for solar inverters and combiner boxes requiring surge protection.
Commercial & Industrial Applications: Suitable for TT and TN-S network systems.
NEC & UL Compliant Sites: UL 1449, IEC 61643-11, and EN 61643-11 certified.
Specifications Table
| Specification | Data |
|---|---|
| Model | DC_SPD_KIT7_T1T2 |
| Nominal Voltage | 277 V AC |
| Max Operating Voltage (L-N / N-PE) | 350 V / 305 V |
| Nominal Discharge Current (8/20 μs) | 20 kA / 40 kA |
| Max Discharge Current (8/20 μs) | 50 kA / 65 kA |
| Impulse Discharge Current (10/350 μs) | 12.5 kA (L-N / N-PE) |
| Voltage Protection Level | 1750 V / 1500 V |
| Short-Circuit Current Rating (AC) | 25 kA / 50 kA |
| Response Time | < 25 ns / < 100 ns |
| Operating Temperature | -40°F to +185°F (-40°C to +85°C) |
| Protection Class | Class I + II / Type 1 + 2 |
| Mounting | 35 mm DIN Rail |
| IP Rating | IP20 (built-in) |
| Weight | 1.397 lbs |
| Housing Material | Thermoplastic, UL 94 V-0 |
| Certifications | UL 1449 4th Ed, IEC/EN 61643-11 |
