24 Panel Commercial Sinclair Sky Rack 2.0 Ground Mount Racking Solar Kit (Seasonal Adjust)

89.5 x 44.5" Panel Size

Panels not included

PLAN NOTE:  Purchase of the Sinclair Sky Rack 2.0 includes a site specific plan package without a stamp. State permit authorities may require additional engineering documents, which can be accommodated at an additional fee. A form will be sent after purchase to complete site specific plans.

STRUCTURAL NOTE: Rated for 125 mph Wind Load & 60 PSF Snow Load. Additional design features available for requirements over 125 mph & 60 PSF. Contact US Solar Supplier at sales@ussolarsupplier.com for more info.

This kit is engineered for commercial-sized panels with the following dimensions:

Dimensional tolerances applied.

Length 89.69″ ± 1.5″

Width 44.65″ ± 1.0″

All other panel sizes will need custom engineering. Contact us.

Examples Include:

Sky-Rack 2.0 Ground Mount System

The Sky-Rack 2.0 is engineered for performance and install efficiency:

• Composed of four main structural components: C-channel posts, trusses, support struts, and Z-purlins
• Designed for fast installation and reduced complexity
• UL 2703 certified for bonding, grounding, and safety
• Built with galvanized steel components for durability
• Backed by a 25-year warranty

Seasonal Tilt Adjustment

The Sinclair Sky-Rack 2.0 gives you the flexibility to dial in production across the seasons:

• Fixed Tilt Option: 5° to 35° for standard installs
• Seasonal Adjust Range: 15° to 60° for optimized year-round output

Real Benefit:

• Steeper tilt in winter (up to 60°) improves low-angle sun capture and helps shed snow
• Lower tilt in summer increases total daily production
• Adjustments can be made incrementally to maintain system performance

This flexibility translates directly into higher annual energy yield compared to fixed systems.

Product Specifications

Mounting System Specs (Sky-Rack 2.0)
