Victron MultiPlus-II 48/3000/35-32 Inverter Charger PMP482305010
The Victron MultiPlus-II 48/3000/35-32 (Model PMP482305010) is a powerful inverter/charger ideal for residential, marine, and off-grid systems. It features 3000VA of inverter power, a 35A battery charger, and integrated PowerAssist technology. Compatible with Victron’s Energy Storage System (ESS), it allows seamless solar integration and uninterrupted backup power. The unit includes dual AC outputs, VE.Bus communication, and flexible system configuration capabilities.
Key Benefits
Pure Sine Wave Inverter: 3000VA continuous output with 5500W peak surge capacity.
35A Battery Charger: Smart 4-stage charger for safe and efficient charging.
Dual AC Output: Connect critical and non-critical loads separately.
ESS-Ready: Integrates with solar inverters and PV charge controllers for grid-tied or off-grid energy storage systems.
Remote Monitoring: Compatible with Cerbo GX and Victron VRM for internet-based access.
Special Technology
PowerControl & PowerAssist: Prevents generator overload and boosts grid power during peak demand.
VE.Bus Communication: Enables multi-unit parallel or 3-phase configurations.
Integrated Transfer Switch: 32A automatic switching between grid and inverter modes.
Remote On/Off & Programmable Relay: Advanced logic for alarms and genset triggering.
Bluetooth & App Integration: Configure and monitor via VictronConnect with VE.Bus Smart Dongle.
Warranty
Victron backs the PMP482305010 with a robust 5-year limited warranty, extendable through product registration.
Best Use
Off-Grid Cabins & Remote Homes: Delivers uninterrupted power with solar integration support.
Marine & Mobile Systems: High-performance inverter for yachts, RVs, and expedition vehicles.
Residential Energy Storage: Ideal for grid-tied battery backup with solar compatibility.
Commercial Backup Power: Protects mission-critical systems during outages or voltage fluctuations.
Specifications Table
| Specification | Data |
|---|---|
| Model Number | PMP482305010 |
| Nominal DC Voltage | 48 VDC |
| Continuous Output Power (25°C) | 3000 VA / 2400 W |
| Surge Power | 5500 W |
| Output Voltage / Frequency | 230 VAC ±2% / 50 Hz ±0.1% |
| Max Efficiency | 95% |
| Battery Charger Current | 35 A |
| Transfer Switch | 32 A |
| AC Input Voltage Range | 187–265 VAC |
| AC Input Frequency | 45–65 Hz |
| Zero Load Power | 11 W (Normal), 7 W (AES), 2 W (Search Mode) |
| Operating Temperature | –40°F to 149°F (–40°C to +65°C) |
| Protection Features | Overload, Short Circuit, Over/Under Voltage, Over Temp |
| Communications | VE.Bus, 2× GP ports, Remote On/Off |
| Parallel & 3-Phase Ready | Yes |
| Enclosure Material | Steel, Blue (RAL 5012) |
| Ingress Protection | IP22 |
| Dimensions (H × W × D) | 19.6 × 10.6 × 5.6 in |
| Weight | 41.9 lbs |
| Certifications | EN-IEC 60335, 62109, 61000-3, CE, RoHS |
| Warranty | 5-Year Limited Warranty |
About Victron:
Victron Energy is a Dutch company founded in 1975, designing and manufacturing battery-based energy system products—sine‑wave inverters, inverter‑chargers, solar charge controllers, monitoring—and supporting a modular, off-grid/marine/RV ecosystem.
