Victron SmartSolar MPPT RS 450/200-MC4 SCC145120510 Charge Controller
SCC145120510
Victron SmartSolar MPPT RS 450/200-MC4 SCC145120510 Charge Controller
The Victron Energy SCC145120510 is a SmartSolar MPPT 450/200-MC4 charge controller designed to maximize solar energy harvesting for off-grid, hybrid, marine, and RV power systems. With a wide 450V PV input range and a 200A output capacity, it’s suitable for battery banks of 48V.
Built-in Bluetooth and MC4 connectors make installation and monitoring fast, safe, and easy. It’s the ideal solution for managing solar energy storage in small to mid-sized systems.
Key Benefits
Advanced MPPT Algorithm: Maximizes solar yield by dynamically tracking the optimum power point—even in partial shade.
High Input Voltage: Accepts up to 450V PV input, reducing wire size and cost with longer solar array distances.
45A Output Current: Efficiently charges 48V battery banks from your solar array.
Integrated Bluetooth: Monitor and configure settings wirelessly using the VictronConnect app.
Plug-and-Play MC4 Connectors: Simplifies PV input wiring with secure, weatherproof connections.
Special Technology
Ultra-Fast Maximum Power Point Tracking (MPPT): Increases energy harvest compared to PWM and slower MPPT methods.
Intelligent Load Output: Optional load terminal disconnects loads to prevent deep battery discharge.
Remote Monitoring Ready: Connect to Victron’s VRM Portal via a GX device or GlobalLink 520.
Battery Compatibility: Supports lead-acid, AGM, gel, and lithium batteries with programmable charge profiles.
Electronic Protection: Safeguards against short circuit, reverse polarity, over-temperature, and more.
Warranty
The Victron SmartSolar MPPT 450/200-MC4 (SCC145120510) is backed by a 5-year limited warranty, providing confidence in its long-term reliability and performance in solar energy systems.
Best Use
Off-Grid Solar Systems: Ideal for cabins, tiny homes, and remote properties needing efficient solar charging.
RVs & Camper Vans: Lightweight and compact for vehicle-mounted solar setups with plug-and-play MC4 input.
Marine Applications: Powers battery banks on yachts, sailboats, and houseboats with robust weather resistance.
Small Commercial & Backup Systems: Reliable charge controller for critical infrastructure or hybrid energy setups.
Specifications Table
| Specification | Data |
|---|---|
| Model | SCC145120510 |
| Product Name | SmartSolar MPPT 450/200-MC4 |
| PV Input Voltage (Max) | 450V DC |
| Battery Voltage | 48V |
| Max Battery Charge Current | 200A |
| Nominal PV Power (48V) | ~2600W |
| MPPT Efficiency | Up to 99% |
| Bluetooth | Built-In |
| Load Output | Yes (15A Max) |
| PV Connection | MC4 |
| Dimensions (L × W × H) | 19.2 × 17.1 × 5.7 inches |
| Weight | 30.2 lbs |
| Certifications | CE, RoHS, UL Pending |
| Warranty | 5-Year Limited Warranty |
